4. ACCESSORIES

4.1. CARDIO THEATER CONNECTION

The machine can be connected to the Cardio Theater by means of the RJ45 connector on the C-Safe
board. The Cardio Theater unit must be provided with a power cable having the following pin-out:
RJ45 Connector
WARNING: for the numbering of the pins, on RJ45 connector, please refer to the
diagram below:
5
7
Signal
+5Vdc
Ground
Page 4.1
