CHAPTER 7– SERVICE AND REPAIR
Chapter 7 Service and Repair
Do not service MultiLoad III/RCU III DIV2 Hardware without disconnecting the
supply circuit. Keep the enclosure tightly closed while circuits are live.
Using a magnetic screwdriver is very helpful in retaining the screws during removal and
installation.
Overview and Subassemblies
46
Figure 7.1
MultiLoad III / RCU III DIV2 Hardware Unit
MultiLoad III/RCU III DIV2 Hardware Installation Guide - Part # 6074
7
Chapter
CARD READER
ON SIDE
DISPLAY
KEYPAD
