CHAPTER 3– INSTALLING THE MULTILOAD III/RCU III DIV2 HARDWARE
Exterior dimensions of the standard MultiLoad III/RCU III DIV2 Hardware enclosure are shown in
Figures 2.2 –2.7. There is only one mounting orientation possible: reference Figure 2.2 for the
MultiLoad III/RCU III DIV2 Hardware Mounting Template. The cable entries are located at the bottom
of the unit.
Appropriate fasteners must be selected to support the minimum weight of 29.1 lbs (13.2 kg). Toptech
offers the following mounting suggestions for three typical surfaces: drywall, wood, or concrete/cinder
block.
Metal Plate or Rail
Use four hex head 3/8" OD (M10) bolts with a 3/8" flat washer, 3/4" OD (M10, 20mm OD) under the head of
the bolt. Tighten with four 3/8" (M10) hex nuts.
Wood
Use four hex head 2" x 3/8" OD (M10 x 50 mm) lag bolts with a 3/8" flat washer, 3/4" OD (M10, 20 mm OD)
under the head of the bolt. Or, you may drill through holes in the wood and assemble as with the metal plate
using four hex head 3/8" OD (M10) bolts with a 3/8" flat washer, 3/4" OD (M10, 20 mm OD) under the head
of the bolt. Tighten with four 3/8" (M10) hex nuts
Concrete or Cinder Block Walls
Use four Sleeve, Bolt and Stud Anchors, Hex Nut 3/8"OD, 2 1/4"long or a metric equivalent.
Mounting Height Considerations
When mounting the enclosure, be aware of the limitations that the cover places on screen visibility.
Because the display is inset about an ½" [12.7mm] from the surface, the enclosure should be mounted
so that top of the screen's visible area is at eye level of the tallest operator. Figure 3.1 shows the
visible area at arm's length and the distance from the ground to the top mounting hole location for a six-
foot [1.8m] tall user. Figure 3.2 shows the offset of the top of the screen's visible area from the top
mounting bolt and the depth of the screen within the unit.
18
.
MultiLoad III/RCU III DIV2 Hardware Installation Guide - Part # 6074
