CHAPTER 6– CONFIGURATIONS
Verifying Communications with FCMs.
Enter program mode by pressing 00000 on the keypad, then press Down key.
1)
Select diagnostics from main menu:
2)
43
MultiLoad II+ Firmware
D I A G N O S T I C S
Card Reader
COM Loopback
Serial Ports
PTB Serial –Test
Network Test
Keypad
Display
Unicode
FCM Com
PCM Com
FCM Health
PCM Health
RCU
Bay
Down
RCU II+ Firmware
D I A G N O S T I C S
Card Reader
COM Loopback
Serial Ports
Network Test
Down
MultiLoad III/RCU III DIV2 Hardware Installation Guide - Part # 6074
M E N U
Preset
Meters
Components
Additives
Sampler
Custom Logic
Modbus Device
Thread Info
SD Card
Up
Exit
OK
M E N U
Keypad
Display
Unicode
RCU
Up
Exit
OK
