Chapter 3. Using RXT Drives in the RXT350

Interpreting the Web Interface

Figure 3-1 shows an example web interface screen.
Toolbars
Refresh Date & Time Current User Hostname
Messages
Status
Figure 3-1
The features of the web interface (the RXT Media Status screen is shown).
General Toolbar Select this toolbar to display RXT drive and media status.
Configuration Toolbar Select this toolbar to access network configuration options and
date and time settings.
Maintenance Toolbar Select this toolbar to access firmware management and more.
Refresh Select this icon to refresh the current screen.
Messages Select this icon to display the Messages screen. For information about
messages, refer to Web Interface Messages on the next page.
Status Select this icon to display the RXT Drive Status screen.
Date & Time Check this for the current date and time set on the drive. To change the
date and time, see Setting the Date and Time on page 32.
Current User Check this to identify the logged-in user. To change users, select the
current user. This logs out the current user and displays the login screen.
Hostname Check this to determine the name of the RXT350 as it appears to the host;
by default, it consists of the letters RXT plus part of the RXT350's serial number. To
change the hostname, see Editing Network Settings on page 29.
23
