Hardware Design Files
Designator Quantity
R2_1, R2_2, R2_3, R2_4,
R2_5, R2_6, R2_7, R2_8,
R9, R13, R16, R18, R22, 19
R25, R27, R28, R29, R31,
R45
R3_1, R3_2, R3_3, R3_4,
8
R3_5, R3_6, R3_7, R3_8
R4_1, R4_2, R4_3, R4_4,
8
R4_5, R4_6, R4_7, R4_8
R5_1, R5_2, R5_3, R5_4,
R5_5, R5_6, R5_7, R5_8,
R6_1, R6_2, R6_3, R6_4, 21
R6_5, R6_6, R6_7, R6_8,
R30, R48, R63, R65, R66
R7_1, R7_2, R7_3, R7_4,
R7_5, R7_6, R7_7, R7_8, 9
R38
R8, R10, R17, R19, R39,
R40, R43, R46, R49, R55, 11
R61
R11, R20 2
R12, R21 2
R32 1
R33 1
R34 1
R35 1
R36 1
50 BOOSTXL-IOLINKM-8 EVM User's Guide
Value Description
RES, 10 k, 5%, 0.063 W,
10k
AEC-Q200 Grade 0, 0402
RES, 0, 5%, 0.063 W,
0
AEC-Q200 Grade 0, 0402
RES, 240, 5%, 0.063 W,
240
AEC-Q200 Grade 0, 0402
RES, 4.99 k, 1%, 0.063 W,
4.99k
0402
RES, 49.9 k, 1%, 0.063 W,
49.9k
AEC-Q200 Grade 0, 0402
0 RES, 0, 5%, 0.063 W, 0402 0402
RES, 3.32 k, 1%, 0.063 W,
3.32k
AEC-Q200 Grade 0, 0402
RES, 1.40 k, 1%, 0.063 W,
1.40k
AEC-Q200 Grade 0, 0402
RES, 24.3 k, 1%, 0.063 W,
24.3k
AEC-Q200 Grade 0, 0402
RES, 887 k, 1%, 0.063 W,
887k
AEC-Q200 Grade 0, 0402
RES, 499 k, 1%, 0.063 W,
499k
AEC-Q200 Grade 0, 0402
RES, 68.1 k, 1%, 0.063 W,
68.1k
0402
RES, 29.4 k, 1%, 0.063 W,
29.4k
AEC-Q200 Grade 0, 0402
Copyright © 2023 Texas Instruments Incorporated
Part Number
Package
Reference
0402 CRCW040210K0JNED
0402 CRCW04020000Z0ED
0402 CRCW0402240RJNED
0402 RC0402FR-074K99L
0402 CRCW040249K9FKED
RC0402JR-070RL
0402 CRCW04023K32FKED
0402 CRCW04021K40FKED
0402 CRCW040224K3FKED
0402 CRCW0402887KFKED
0402 CRCW0402499KFKED
0402 RC0402FR-0768K1L
0402 CRCW040229K4FKED
Manufacturer Alternate
PartNumber Manufacturer
Vishay-Dale
Vishay-Dale
Vishay-Dale
Yageo America
Vishay-Dale
Yageo America
Vishay-Dale
Vishay-Dale
Vishay-Dale
Vishay-Dale
Vishay-Dale
Yageo America
Vishay-Dale
