Hardware Design Files
Designator Quantity
C28 1
C32 1
C33 1
C34 1
C37, C38, C39 3
D1_1, D1_2, D1_3, D1_4,
D1_5, D1_6, D1_7, D1_8, 11
D6, D9, D11
D2_1, D2_2, D2_3, D2_4,
D2_5, D2_6, D2_7, D2_8, 11
D5, D8, D10
D3_1, D3_2, D3_3, D3_4,
8
D3_5, D3_6, D3_7, D3_8
D4_1, D4_2, D4_3, D4_4,
D4_5, D4_6, D4_7, D4_8,
D12_1, D12_2, D12_3, 16
D12_4, D12_5, D12_6,
D12_7, D12_8
D7 1
FID1, FID2, FID3, FID4,
6
FID5, FID6
J1_1, J1_2, J1_3, J1_4,
8
J1_5, J1_6, J1_7, J1_8
J2, J3, J4, J5 4
48 BOOSTXL-IOLINKM-8 EVM User's Guide
Value Description
CAP, CERM, 10 pF, 50
10pF V, +/- 5%, C0G/NP0, AEC-
Q200 Grade 1, 0402
CAP, CERM, 2.2 uF, 50 V,
2.2uF
+/- 10%, X7R, 0805
CAP, CERM, 10 µF, 25
10uF
V,+/- 10%, X7R, 1206
CAP, CERM, 0.1 uF, 50 V,
0.1uF
+/- 10%, X7R, 0603
CAP, CERM, 0.01 µF, 16
0.01uF
V,+/- 10%, X7R, 0402
Green LED, Green, SMD
Super Red LED, Super Red, SMD
Blue LED, Blue, SMD
Diode, Switching, 75 V, 0.3
75V
A, SOD-523F
Diode, TVS, Bi, 33 V, 53.3
33V
Vc, 1500 W, 200 A, SMC
Fiducial mark. There is
nothing to buy or mount.
Sensor Connector, M12,
Receptacle, 5 Contacts,
PCB Socket, Straight Panel
Mount
Receptacle, 2.54mm, 10x2,
Gold, SMT
Copyright © 2023 Texas Instruments Incorporated
Part Number
Package
Reference
CGA2B2C0G1H100D050B
0402
A
0805 C2012X7R1H225K125AC
1206 C3216X7R1E106K160AB
0603 C0603C104K5RACTU
0402 CC0402KRX7R7BB103
LED_0603 150060VS75000
LED_0603 150060SS75000
LED_0603 150060BS75000
SOD-523F 1N4148WT
SMC SMCJ33CA-13-F
N/A N/A
PTH_CIRCULAR
T4141012051-000
_CONNECTOR
Receptacle,
2.54mm, 10x2, NPPC102KFMS-RC
SMT
Manufacturer Alternate
PartNumber Manufacturer
TDK
TDK
TDK
Kemet
Yageo
Wurth Elektronik
Wurth Elektronik
Wurth Elektronik
Fairchild
Semiconductor
Diodes Inc.
N/A
TE Connectivity
Sullins Connector
Solutions
