User's Guide

BOOSTXL-TPS65033 User's Guide

This document outlines the basic hardware and software components for the BOOSTXL-TPS65033 Socketed

Programming Board. The BoosterPack enables pre-assembly programming for both the TPS650320-Q1 and the

TPS65033x-Q1 devices. The TPS65032001-Q1 and TPS65033000-Q1 are re-configurable PMICs for

prototyping various device settings. The settings can then be provided to TI for a final production PMIC.

Alternatively, the TPS65032001-Q1 and TPS65033000-Q1 devices can be programmed in production to match a

wide range of application requirements. The non-safety versions of the TPS650320-Q1 and TPS65033x-Q1 will

similarly allow programming of production units.

1 BOOSTXL-TPS65033 Components and

2 BOOSTXL-TPS65033 Board Information..............................................................................................................................

2.1 Critical Socketed Board

2.2 Jumpers and Test

Points....................................................................................................................................................4

3 Programming GUI Operation.................................................................................................................................................

3.1 Initial Set-up.......................................................................................................................................................................

3.2 Connection

Debugging.......................................................................................................................................................9

3.3 Basic Operation of the GUI..............................................................................................................................................

3.4 Scripting...........................................................................................................................................................................

4 Recommended Operating Procedure.................................................................................................................................

5 BOOSTXL-TPS65033 Schematic.........................................................................................................................................

6 BOOSTXL-TPS65033 Board Layers....................................................................................................................................

7 BOOSTXL-TPS65033 Bill of

8 Revision History...................................................................................................................................................................

Trademarks

™

Google Chrome

is a trademark of Google, LLC.

Mozilla Firefox

™

is a trademark of Mozilla Foundation.

Windows

is a registered trademark of Microsoft Corporation.

macOS

is a registered trademark of Apple Inc.

Linux

is a registered trademark of The Linux Foundation.

All other trademarks are the property of their respective owners.

SLVUBO3A - APRIL 2019 - REVISED OCTOBER 2020

Submit Document Feedback

ABSTRACT

Environment.........................................................................................................2

Connections.................................................................................................................................3

Materials.................................................................................................................................26

Table of Contents

BOOSTXL-TPS65033 User's Guide

Table of Contents

Need help?

Do you have a question about the BOOSTXL-TPS65033 and is the answer not in the manual?

Questions and answers

Summary of Contents for Texas Instruments BOOSTXL-TPS65033

Page 1: Table Of Contents
BOOSTXL-TPS65033 User's Guide ABSTRACT This document outlines the basic hardware and software components for the BOOSTXL-TPS65033 Socketed Programming Board. The BoosterPack enables pre-assembly programming for both the TPS650320-Q1 and the TPS65033x-Q1 devices. The TPS65032001-Q1 and TPS65033000-Q1 are re-configurable PMICs for prototyping various device settings.
Page 2: Boostxl-Tps65033 Components And Environment
The TPS65032001-Q1 and TPS65033x-Q1 family of PMICs are configurable and programmable only through I2C instructions. The BOOSTXL-TPS65033 socketed board is designed to act as a BoosterPack to the low cost TI LaunchPads, enabling a LaunchPad to act as the USB-to-I2C interface for communication with a personal computer.
Page 3: Critical Socketed Board Connections
PMIC can supply VIO when externally connected to an appropriate test point, for example the Buck 1 output if configured for 3.3 V, or the Buck 2 output if configured for 1.8 V. SLVUBO3A – APRIL 2019 – REVISED OCTOBER 2020 BOOSTXL-TPS65033 User's Guide Submit Document Feedback Copyright © 2020 Texas Instruments Incorporated...
Page 4: Jumpers And Test Points
S2 toggle switch on the top left area of the board. See Section 5 for the complete BOOSTXL-TPS65033 schematic. It is recommended to keep S2 open when connecting the LaunchPad to the PC to reduce the initial current draw from the USB port.
Page 5: Programming Gui Operation
3 Programming GUI Operation 3.1 Initial Set-up 3.1.1 Finding the GUI The Graphical User Interface (GUI) for the BOOSTXL-TPS65033 can be found in the Gallery DevTools. This GUI will connect to the BOOSXL-TPS65033 provided a compatible I2C controller is connected (MSP430F5529LP, MSP432E401Y, or USB2ANY).
Page 6 3. Connect the LaunchPad to the PC. Use the USB port on the MSP432E401Y LaunchPad that is opposite the Ethernet port. 4. Run UniFlash. The program should automatically detect the connected MSP432E401Y LaunchPad. Once detected, click Start. BOOSTXL-TPS65033 User's Guide SLVUBO3A – APRIL 2019 – REVISED OCTOBER 2020 Submit Document Feedback Copyright © 2020 Texas Instruments Incorporated...
Page 7 6. If prompted, update the XDS110 Debugger firmware. After accepting the update, UniFlash will update the firmware automatically and continue to load the binary image. The console will indicate a successful program. SLVUBO3A – APRIL 2019 – REVISED OCTOBER 2020 BOOSTXL-TPS65033 User's Guide Submit Document Feedback Copyright © 2020 Texas Instruments Incorporated...
Page 8 9. Install jumper on pins 3-4 (USB-OTG) of JP1 to supply the target 5 V supply through USB. After completing this process, the GUI will recognize the LaunchPad as a USB-to-I2C interface. Next, stack the BOOSTXL-TPS65033 on top of the MSP432E401Y LaunchPad. The headers should align according to Table 3-1.
Page 9: Connection Debugging
LaunchPad. The flow chart in Figure 3-11 can aid in debugging potential connection issues with the BOOSTXL- TPS65033. Figure 3-10. Refreshing the GUI-to-MCU Connection SLVUBO3A – APRIL 2019 – REVISED OCTOBER 2020 BOOSTXL-TPS65033 User's Guide Submit Document Feedback Copyright © 2020 Texas Instruments Incorporated...
Page 10: Basic Operation Of The Gui
The Home section is the landing page of the GUI. Here the GUI presents an overview of the EVM and Programming BoosterPack (BOOSTXL-TPS65033), and emphasize navigation to the remaining four sections through the tiles on the bottom of the page.
Page 11 The Registers section provides an overview of the internal register map, and includes basic interfaces for each PMIC register. Figure 3-14 illustrates the register page and the primary interactive regions. SLVUBO3A – APRIL 2019 – REVISED OCTOBER 2020 BOOSTXL-TPS65033 User's Guide Submit Document Feedback Copyright © 2020 Texas Instruments Incorporated...
Page 12: Device Configuration
EVM and write instructions appear to be ignored by the PMIC, confirm the status of these indicators to verify the device is able to accept new write instructions. BOOSTXL-TPS65033 User's Guide SLVUBO3A – APRIL 2019 – REVISED OCTOBER 2020 Submit Document Feedback Copyright © 2020 Texas Instruments Incorporated...
Page 13 PMIC. This drop down box will not be adjustable if a device is connected to the GUI. SLVUBO3A – APRIL 2019 – REVISED OCTOBER 2020 BOOSTXL-TPS65033 User's Guide Submit Document Feedback Copyright © 2020 Texas Instruments Incorporated...
Page 14 TI recommends to set Power On Bit unmasked for each rail that is required in the application. BOOSTXL-TPS65033 User's Guide SLVUBO3A – APRIL 2019 – REVISED OCTOBER 2020 Submit Document Feedback Copyright © 2020 Texas Instruments Incorporated...
Page 15 For example, if a regulator is enabled but fails to power-up within 200 ms, the sequence settings are not valid. SLVUBO3A – APRIL 2019 – REVISED OCTOBER 2020 BOOSTXL-TPS65033 User's Guide Submit Document Feedback Copyright © 2020 Texas Instruments Incorporated...
Page 16: Scripting
.js or .txt file, and imported using the Upload arrow at the top of the scripting window. Scripting allows the re- configuration of multiple PMICs before sending to assembly or populating on a PCB. Figure 3-21. TPS6503xx-Q1 GUI Scripting Window BOOSTXL-TPS65033 User's Guide SLVUBO3A – APRIL 2019 – REVISED OCTOBER 2020 Submit Document Feedback Copyright © 2020 Texas Instruments Incorporated...
Page 17 Most blocks can be executed with one or more register write commands in the script file. Only the J2 configuration and GPIO trigger application cannot be done via scripting. SLVUBO3A – APRIL 2019 – REVISED OCTOBER 2020 BOOSTXL-TPS65033 User's Guide Submit Document Feedback Copyright © 2020 Texas Instruments Incorporated...
Page 18 Programming GUI Operation www.ti.com Figure 3-22. Example Script Program Flow BOOSTXL-TPS65033 User's Guide SLVUBO3A – APRIL 2019 – REVISED OCTOBER 2020 Submit Document Feedback Copyright © 2020 Texas Instruments Incorporated...
Page 19: Recommended Operating Procedure
4 Recommended Operating Procedure • Due to the parasitic elements introduced by the BOOSTXL-TPS65033 socket, it is recommended to use the BOOSTXL-TPS65033 board primarily for digital evaluation. This includes features like NVM programming, state machine behavior, diagnostics, and fault handling.
Page 20: Boostxl-Tps65033 Schematic
GPIO ! SPI_CS/GPIO ! GPIO ! SPI_CS/GPIO ! GPIO ! GPIO ! TP10 SSQ-110-03-T-D Figure 5-1. BOOSTXL-TPS65033 LaunchPad and Socket Connections BOOSTXL-TPS65033 User's Guide SLVUBO3A – APRIL 2019 – REVISED OCTOBER 2020 Submit Document Feedback Copyright © 2020 Texas Instruments Incorporated...
Page 21 10uF LX_B3 FB_B3 Net-Tie 10µF Internal Supply Capacitors VLDO TP17 VREG TP16 V1P8_INT TP18 AGND Figure 5-2. BOOSTXL-TPS65033 Power Supplies SLVUBO3A – APRIL 2019 – REVISED OCTOBER 2020 BOOSTXL-TPS65033 User's Guide Submit Document Feedback Copyright © 2020 Texas Instruments Incorporated...
Page 22: Boostxl-Tps65033 Board Layers
BOOSTXL-TPS65033 Board Layers www.ti.com 6 BOOSTXL-TPS65033 Board Layers Figure 6-1. Top Layer BOOSTXL-TPS65033 User's Guide SLVUBO3A – APRIL 2019 – REVISED OCTOBER 2020 Submit Document Feedback Copyright © 2020 Texas Instruments Incorporated...
Page 23 BOOSTXL-TPS65033 Board Layers Figure 6-2. Mid-Layer 1 SLVUBO3A – APRIL 2019 – REVISED OCTOBER 2020 BOOSTXL-TPS65033 User's Guide Submit Document Feedback Copyright © 2020 Texas Instruments Incorporated...
Page 24 BOOSTXL-TPS65033 Board Layers www.ti.com Figure 6-3. Mid-Layer 2 BOOSTXL-TPS65033 User's Guide SLVUBO3A – APRIL 2019 – REVISED OCTOBER 2020 Submit Document Feedback Copyright © 2020 Texas Instruments Incorporated...
Page 25 BOOSTXL-TPS65033 Board Layers Figure 6-4. Bottom Layer (Mirrored) SLVUBO3A – APRIL 2019 – REVISED OCTOBER 2020 BOOSTXL-TPS65033 User's Guide Submit Document Feedback Copyright © 2020 Texas Instruments Incorporated...
Page 26: Boostxl-Tps65033 Bill Of Materials
BOOSTXL-TPS65033 Bill of Materials www.ti.com 7 BOOSTXL-TPS65033 Bill of Materials Table 7-1. BOOSTXL-TPS65033 Bill of Materials (BOM) Designator Quantity Value Description Package Reference Part Number Manufacturer !PCB1 Printed Circuit Board BMC059 C1, C7 1 µF CAP, CERM, 1 µF, 35 V, ±...
Page 27 BOOSTXL-TPS65033 Bill of Materials Table 7-1. BOOSTXL-TPS65033 Bill of Materials (BOM) (continued) Designator Quantity Value Description Package Reference Part Number Manufacturer R7, R8, R9 RES, 0, 5%, 0.063 W, 0402 RC0402JR-070RL Yageo America 0402 S1, S3 Switch, Slide, SPDT, On- 9.5x5 mm...
Page 28: Revision History
Changes from Revision * (April 2019) to Revision A (October 2020) Page • Changed the title from TPS65033x Programming Board Users Guide to BOOSTXL-TPS65033 EVM User's Guide ................................. • Updated the numbering format for tables, figures, and cross-references throughout the document....1...
Page 29 STANDARD TERMS FOR EVALUATION MODULES Delivery: TI delivers TI evaluation boards, kits, or modules, including any accompanying demonstration software, components, and/or documentation which may be provided together or separately (collectively, an “EVM” or “EVMs”) to the User (“User”) in accordance with the terms set forth herein.
Page 30 www.ti.com Regulatory Notices: 3.1 United States 3.1.1 Notice applicable to EVMs not FCC-Approved: FCC NOTICE: This kit is designed to allow product developers to evaluate electronic components, circuitry, or software associated with the kit to determine whether to incorporate such items in a finished product and software developers to write software applications for use with the end product.
Page 31 www.ti.com Concernant les EVMs avec antennes détachables Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage radioélectrique à...
Page 32 www.ti.com EVM Use Restrictions and Warnings: 4.1 EVMS ARE NOT FOR USE IN FUNCTIONAL SAFETY AND/OR SAFETY CRITICAL EVALUATIONS, INCLUDING BUT NOT LIMITED TO EVALUATIONS OF LIFE SUPPORT APPLICATIONS. 4.2 User must read and apply the user guide and other available documentation provided by TI regarding the EVM prior to handling or using the EVM, including without limitation any warning or restriction notices.
Page 33 Notwithstanding the foregoing, any judgment may be enforced in any United States or foreign court, and TI may seek injunctive relief in any United States or foreign court. Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265 Copyright © 2019, Texas Instruments Incorporated...
Page 34 TI products. TI’s provision of these resources does not expand or otherwise alter TI’s applicable warranties or warranty disclaimers for TI products.IMPORTANT NOTICE Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265 Copyright © 2021, Texas Instruments Incorporated...
