Hardware Installation and Reference Guide
Figure 3-6 Attaching the Mounting Bracket to the Wall
53 mm
(2.09 in.)
Wall anchor
(2) Align the square feet on the rear of the AP with the mounting holes on the bracket.
Figure 3-7 Aligning the Square Feet with the Mounting Holes
Caution
Install the Ethernet cables before mounting the AP on the bracket.
(3) Slide the AP into the holes in the opposite direction of the arrows on the mounting
bracket until it clicks into place.
Diameter:
6.5 mm
53 mm
(0.26 in.)
(2.09 in.)
DC power supply
Screw
or PoE
Install the Ethernet
cable before mounting
the AP on the bracket.
26
Installing the AP
