Command Byte: '3'
Parameter: None
Response: "AB" formatted as follows:
Byte 'A'
Bit 7: Reserved.
Bit 6: Complement of bit 5.
Bit 5: Latched Helix Arc Fault.
Bit 4: Momentary Helix Arc Fault.
Bit 3: TWT Over Temp Fault.
Bit 2: Cathode Over Voltage Fault.
Bit 1: Reserved
Bit 0: Low Line.
Parameter: '# extended fault status'
Response: "ABCD"
Byte 'C'
Bit 7: Reserved.
Bit 6: Compliment of Bit 5.
Bit 5: Reserved.
Bit 4: Cover Interlock.
Bit 3: Fast VSWR
Bit 2: Reserved.
Bit 1: Reserved.
Bit 0: Phase Lock (future).
Notes:
1 Byte B, Bit 1, 2, and 4 are user settable alarms for High Output Power, Low Output Power, and High
Reflected Power respectively. A High Reflected Power fault can also occur when the VSWR detec-
tion circuit trips.
2. Byte A, Bit 3, TWT Over Temp fault: This bit is set when the temperature on the collector of the TWT
exceeds the manufacturers safe operation specification. This is a non-latching fault. Upon
detecting a fault, the amplifier will shut off the High Voltage to the tube. The TWT temperature will
cool down until safe to operate again; the High Voltage will be automatically turned back up.
3. Byte A, Bit 2 Cathode Over Voltage fault: This bit is set when the Cathode voltage applied to the
TWT exceeds the safe operation threshold. This is a latching fault that has to be reset with the
reset command.
4. Byte B, Bit 5 Cathode Under Voltage fault. This bit is set when the Cathode voltage applied to the
TWT is below a safe operation threshold. This is a latching fault that has to be reset with the reset
command.
MNC-0500-038
EAR EXPORT CONTROLLED: The information contained in this Manual refers or relates to a product that is subject
to the U.S. Export Administration Regulations (EAR). Transfer of data herein by any means to a Foreign Person,
whether in the U.S. or abroad, may require an export license from the U.S. Department of Commerce.
Amplifier Communication and Protocol, XTRT, Touchscreen TWTA
Fault Status
Byte 'B'
Bit 7: Reserved.
Bit 6: Complement of bit 5.
Bit 5: Cathode Under Voltage Fault.
Bit 4: High Reflected Power.
Bit 3: External Interlock open or cable interlock.
Bit 2: Low Output Power.
Bit 1: High Output Power.
Bit 0: Waveguide Arc Fault (If configured with a
waveguide arc detector).
Byte 'D'
Bit 7: Reserved.
Bit 6: Compliment of Bit 5.
Bit 5:
Bit 4: Upconverter Fault (If configured with
Upconverter).
Bit 3: RF Power Limit Fault. (software overdrive)
Bit 2: Reserved.
Bit 1: Overdrive Fault.
Bit 0: Thermal Interlock.
