240x135 pixels and is
connected to a separate pin so you can PWM the backlight up and down as desired.
For low power usages, the Feather has a second low-dropout 3.3V regulator. The
regulator is controlled with a GPIO pin on the enable line and can shut off power to
the Stemma QT port and TFT. There is also a separate power pin for the NeoPixel that
can be used to disable it for even lower quiescent power. With everything off and in
deep sleep mode, the TFT feather uses about 100uA of current.
Features:
• ESP32-S3 Dual Core 240MHz Tensilica processor - the next generation of
ESP32-Sx, with native USB so it can act like a keyboard/mouse, MIDI device,
disk drive, etc!
• Mini module has FCC/CE certification and comes with 4 MByte of Flash and 2
MByte of PSRAM - you can have huge data buffers.
• Color 1.14" IPS TFT with 240x135
ST7789 chipset that can be viewed at any angle angle.
• Power options - USB type C or Lipoly battery
• Built-in battery charging when powered over USB-C.
• LiPoly battery monitor - LC709203 chip actively monitors your battery for
voltage and state of charge / percentage reporting over I2C.
• Reset and DFU (BOOT0) buttons to get into the ROM bootloader (which is a USB
serial port so you don't need a separate cable!)
• Serial debug output pin (optional, for checking the hardware serial debug
console)
©Adafruit Industries
IPS () so you get bright color at any angle. The backlight is also
pixels () - bright and colorful display with
