Removing the right AlienFX side-panel connector
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow the steps
in
Before working inside your
computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/regulatory_compliance.
Topics:
•
Prerequisites
•
Procedure
Prerequisites
1. Remove the
stability
foot.
2. Remove the left and right side-panels. See
Procedure
1. Lay the chassis on the left side.
2. Disconnect the right AlienFX side-panel cable that connects the right AlienFX side-panel connector to the I/O board. See
"I/O-board
components".
3. Remove the screw (#6-32x6) that secures the right AlienFX side-panel connector assembly to the chassis.
4. Remove the right AlienFX side-panel connector assembly from the chassis.
1. screw
3. right AlienFX side-panel cable
5. Remove the two screws (#6-32x6) that secure the right AlienFX side-panel connector to the bracket.
computer. After working inside your computer, follow the instructions in
"Removing the side
panels".
2. right AlienFX side-panel connector assembly
4. right AlienFX side-panel connector
After working inside your
35
