Replacing the bottom tron-lighting cable
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow the steps
in Before working inside your
computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/regulatory_compliance.
Topics:
•

Procedure

•

Post-requisites

Procedure
1. Route the bottom tron-lighting cables through the slot on the chassis.
2. Route the bottom tron-lighting cables through the routing guide on the chassis.
3. Secure the bottom tron-lighting cables to the chassis using the securing clip.
4. Connect the bottom tron-lighting cables to the logo board.
Post-requisites
1. Replace the base panel.
2. Replace the rear bezel.
3. Replace the front bezel.
4. Replace the handle bars.
5. Replace the PCI fan.
6. Replace the full-length graphics
7. Replace the left and right side-panels. See
8. Replace the stability foot.
116
computer. After working inside your computer, follow the instructions in
cards.
"Replacing the side panels".
After working inside your
