Table 3. System setup options—Main menu (continued)
Main
Discrete Graphics 2
Discrete Graphics 3
Device Information
First HDD
SATA ODD
Second HDD
mSATA Device
M.2 PCIe SSD
System Date
System Time
Table 4. System setup options—Advanced menu
Advanced
Advanced BIOS Features
BIOS Recovery via Hard Drive
BIOS Auto-Recovery
Always Perform Integrity Check
Integrated Devices
Front USB Ports
Rear USB Ports
HD Audio
Integrated NIC1/Wireless LAN
Integrated NIC2
Pxe Option
SATA Operation
PCIE GEN3
Power Management Setup
AC Recovery
Deep Sleep Control
Auto Power On
Displays the second discrete graphics installed on your
computer.
Displays the third discrete graphics installed on your
computer.
Displays the first HDD device information.
Displays the SATA ODD device information.
Displays the second HDD device information.
Displays the mSATA device information.
Displays the M.2 PCIe SSD device information.
Displays the current date in mm/dd/yyyy format.
Displays the current time in hh:mm:ss format.
Allows you to store the recovery image file on the primary hard
drive. Default: Enabled.
Enable the user to recover from certain corrupted BIOS conditions
from a recovery file on the user primary hard drive. Default:
Enabled
Allows you to perform the Integrity check. Default: Enabled
Allows you to enable or disable the front USB ports. Default:
Disabled.
Allows you to enable or disable the rear USB ports. Default:
Disabled.
Allows you to enable or disable the integrated audio controller.
Default: Enabled.
Allows you to enable or disable the NIC1. Default: Enabled.
Allows you to enable or disable the NIC2. Default: Enabled.
Allows you to enable or disable the boot option for legacy
network devices. Default: Disabled.
Allows you to configure the operating mode of the integrated
SATA hard drive controller.
Default: AHCI
Allows you to enable or disable the PCIE GEN3. Default: Enabled.
Sets what action the computer takes when power is restored.
Default: Last State.
Allows you to define the controls when Deep Sleep is enabled.
Default: Enabled in S5 Only.
Enable to set the computer to turn on automatically every day or
on a preselected date and time. This option can be configured only
125
