Mechanical information
Emulation Adapter
Top view of the Emulation Adapter
IEA-TC397XE Compact
Extender
Ordering code
IA292LFBGA-EXTENDER
Side view of the Emulation Adapter, one Extender and Solder part
(each Extender adds approx. 3,25mm)
M
29.1
Side view of the Extender
Top view of the Extender
W
17
Unit (mm)
N
22.4
Unit (mm)
Z
3.25
