Mounting Gripper
Axial mounting （Body tapped）
Use the holes on the body
end surface for positioning.
Vertical mounting （Body tapped）
Side mounting （Body tapped）
Horizontal mounting （Body tapped）
Max. tightening
Model No. Screw
torque (N・m)
MHZA2-6□
M2×0.4
MHZAJ2-6□
Note) Axial mounting type is not available for MHZ2-6□ and MHZJ2-6□.
Model No. Screw
MHZA2-6□
M2x 0.4
MHZAJ2-6□
Note) Except MHZ2-6□ and MHZJ2-6□.
Model No. Screw
MHZ2-6□
MHZJ2-6□
M3 x 0.5
MHZA2-6□
MHZAJ2-6□
Model No. Screw
MHZ2-6□
MHZJ2-6□
M2.5x0.45
MHZA2-6□
MHZAJ2-6□
- 8 -
Max. thread Hole diameter
depth (mm)
φ 7H8(+0.022/0)
0.15 4.5
Max. tightening
Maximum screw-in
torque (N・m) depth (mm)
0.15
Max. tightening
Maximum screw-in
torque (N・m) depth (mm)
0.88
Max. tightening
torque (N・m)
0.49
Hole depth
(mm) (mm)
1.5
4
10
