6
3. Install the battery and add the detector to the wireless system (see the ABAX 2 / ABAX
controller manual or the INTEGRA 128-WRL control panel installer manual). The sticker
with serial number which shall be entered when registering the detector in the system can
be found on the electronics module.
In the INTEGRA / VERSA alarm system, the detector is identified as APD-100.
Simultaneous operation of the detector by the ABAX 2 and ABAX controller /
INTEGRA 128-WRL alarm control panel is not possible.
4. Place the electronics module in the enclosure base and then move it up to lock it.
5. Replace the cover.
6. Put the detector at the place of its future installation.
7. Check the level of signal received from the detector by the ABAX 2 / ABAX controller or
the INTEGRA 128-WRL control panel. If the signal level is lower than 40%, select another
place for installation. Sometimes, it is sufficient to shift the device ten or twenty
centimeters.
The ARF-200 tester makes it possible to check the radio signal strength at the place of
future installation without having to put the detector there.
8. Remove the front cover (Fig. 2) and remove the electronics module (Fig. 3).
9. Make screw holes in the enclosure base.
