Summary of Contents for Satel XD-2
- Page 1 XD-2 Multipurpose detector Firmware version 1.00 xd-2_en 05/21 SATEL sp. z o.o. • ul. Budowlanych 66 • 80-298 Gdańsk • POLAND tel. +48 58 320 94 00 www.satel.eu...
- Page 2 The rating plate of the device is located on the enclosure base. SATEL aims to continually improve the quality of its products, which may result in changes in their technical specifications and software. Current information about the changes being introduced is available on our website.
-
Page 3: Table Of Contents
CONTENTS Features ........................... 2 Description ........................2 Alarms ..........................2 Additional alarm output ..................... 3 Supply voltage control ...................... 3 LED indicator ........................3 Electronics board ......................4 Configuring the detector settings ..................5 Selecting the detector type ....................5 Two output mode enable / disable .................. -
Page 4: Features
Water flood detector Detects flooding in spaces provided with plumbing systems. 1 alarm output. Flood probe is not included with the detector. The FPX-1 probe is offered by SATEL. 2. Description Alarms Opening the tamper switch will turn on the tamper output (tamper alarm). The circumstances... -
Page 5: Additional Alarm Output
SATEL XD-2 Magnetic contact Alarm output will turn on after: moving the magnet away from the detector (opening the window or door), opening the SNS input. Shock detector Alarm output will turn on after: detecting a shock caused by a single strong impact, ... -
Page 6: Electronics Board
XD-2 SATEL The LED is also used during configuration of the shock detector (see: “Configuring the shock detector settings”). You can enable / disable the LED. When disabled, the LED will not indicate the events described above, except for the trouble condition. -
Page 7: Configuring The Detector Settings
SATEL XD-2 tamper switch activated by enclosure opening and removal from mounting surface. The LED is located on the other side of the electronics board. 4. Configuring the detector settings Selecting the detector type Detector type Switch setting Magnetic contact... -
Page 8: Led Enable / Disable
XD-2 SATEL LED enable / disable Switch setting Disabled Enabled Configuring the shock detector settings Use the “SENS.” potentiometer to set the sensitivity of the shock detector (Fig. 2). When a single shock is registered and it reaches the sensitivity threshold, alarm will be triggered. - Page 9 SATEL XD-2 If the detector is to be installed on the window frame, select the upper part of the frame for this purpose. This will reduce the probability of the detector being flooded by accident, when the window is partially or fully open.
- Page 10 XD-2 SATEL 8. Close the detector enclosure. 9. For the magnetic contact, install the magnet (Fig. 5), taking into account the maximum permissible distance from the magnetic sensor (Fig. 6 and 7). The shown distance applies to the magnet located at the height of the sensor. Location of the sensor in the enclosure is shown in Fig.
-
Page 11: Detector Test
The actual detection range should be tested. water flood detector: after submerging the flood probe contacts in water. If a detector is connected to the SNS input, check if the LED on the XD-2 detector will turn ON when that detector is violated. - Page 12 XD-2 SATEL S alarm output ....................... 26 Ω SNS input sensitivity: NC type detector ......................150 ms flood probe ........................1 s Complied with standards .......EN 50130-4, EN 50130-5, EN 50131-1, EN 50131-2-6 Security grade according to EN 50131-2-6 ..............Grade 2 Environmental class according to EN 50130-5 ................
