- Page 1 SLIM-DUAL Digital dual technology motion detector Firmware version 1.00 slim-dual_en 10/19 SATEL sp. z o.o. • ul. Budowlanych 66 • 80-298 Gdańsk • POLAND tel. +48 58 320 94 00 www.satel.eu...
- Page 2 Changes, modifications or repairs not authorized by the manufacturer shall void your rights under the warranty. SATEL aims to continually improve the quality of its products, which may result in changes in their technical specifications and software. Current information about the changes being introduced is available on our website.
-
Page 3: Table Of Contents
CONTENTS Features ........................... 2 Description........................2 Supervision features ......................2 LED indicator ........................2 Electronics board ......................3 Selecting a mounting location................... 4 Installation ........................4 Configuring LED indicator settings ................... 7 Start-up and walk test ....................... 7 Specifications ........................8... -
Page 4: Features
SLIM-DUAL SATEL The SLIM-DUAL detector detects movement in the protected area. This manual applies to the detector with electronics version F. 1. Features Motion detection with two sensors: passive infrared sensor (PIR) and microwave sensor (MW). Adjustable detection sensitivity of both sensors. -
Page 5: Electronics Board
SATEL SLIM-DUAL Enabling the LED by using a jumper If you put a jumper across the LED pins, the LED will be enabled, i.e. it will indicate the above described events (the LED can’t be enabled/disabled remotely). If you do not put a jumper across the pins, the LED will be disabled, but it can be enabled/disabled remotely. -
Page 6: Selecting A Mounting Location
3. Make the openings for screws (Fig. 6 or Fig. 7) and cable in the enclosure base. 4. Pass the cable through the prepared opening. If the detector is to be mounted on the bracket, run the cable as shown in Fig. 7. The BRACKET D is available in SATEL's product range. - Page 7 SATEL SLIM-DUAL 5. Secure the enclosure base to the wall (Fig. 6) or a bracket fastened with screws to the wall or ceiling (Fig. 7). The wall plugs (anchors) delivered with the device are intended for concrete, brick, etc. For other types of surface (drywall, styrofoam), use the appropriately...
- Page 8 SLIM-DUAL SATEL 6. Fasten the electronics board. 7. Connect the wires to the corresponding terminals.
-
Page 9: Configuring Led Indicator Settings
LED to turn on. Figure 10 shows the maximum coverage area of a detector installed at a height of 2.4 m. Figure 10 shows the coverage area of the SLIM-DUAL detector with a wide-angle lens (WD), which is installed in the detector by default. You can use the enclosure cover with another lens. -
Page 10: Specifications
SLIM-DUAL SATEL 8. Specifications Supply voltage ....................12 VDC ±15% Standby current consumption ..................10 mA Maximum current consumption ..................25 mA EOL resistors ......................2 x 1.1 k Outputs alarm (NC relay, resistive load)..............40 mA / 24 VDC tamper (NC) ....................100 mA / 30 VDC Microwave frequency ....................24.125 GHz... - Page 11 SATEL SLIM-DUAL Dimensions ....................62 x 137 x 42 mm Weight..........................101 g 5 year warranty from date of manufacture...
