- Page 1 Wireless carbon monoxide detector ACMD-200 Firmware version 1.02 acmd-200_en 11/24 SATEL sp. z o.o. • ul. Budowlanych 66 • 80-298 Gdańsk • POLAND tel. +48 58 320 94 00 www.satel.pl...
- Page 2 13 August 2005). The device meets the technical regulations of the Eurasian Customs Union. SATEL aims to continually improve the quality of its products, which may result in changes in their technical specifications and software. Current information about the changes being introduced is available on our website.
-
Page 3: Table Of Contents
CONTENTS Features ........................... 2 Description ........................2 Selecting a mounting location ................... 4 Installation ........................4 Battery replacement ......................6 Specifications ........................7... -
Page 4: Features
ACMD-200 SATEL The ACMD-200 detector detects hazardous levels of carbon monoxide. It is designed to work as a stand-alone device or within the ABAX 2 two-way wireless system. The detector is supported by: • ACU-220 / ACU-280 controller (firmware version 6.08 or newer), •... - Page 5 SATEL ACMD-200 short flashes of the LED indicator and two short beeps every 2 seconds. The signaling will stop when the concentration of carbon monoxide drops below a hazardous level. The detector reaction is delayed, hence the end of signaling can take place even a few minutes after the concentration of carbon monoxide has dropped below a hazardous level.
-
Page 6: Selecting A Mounting Location
ACMD-200 SATEL Supervision of carbon monoxide sensor In the event of sensor failure (e.g. end of life), the trouble is indicated by the LED indicator and the sounder. The carbon monoxide sensor life is up to 10 years. Battery status control When the battery voltage is lower than 2.75 V, the low battery is indicated by the LED... - Page 7 SATEL ACMD-200 There is a danger of battery explosion when using a different battery than recommended by the manufacturer, or handling the battery improperly. Do not crush the battery, cut it or expose it to high temperatures (throw it into the fire, put it in the oven, etc.).
-
Page 8: Battery Replacement
1. Start the service mode in the control panel (if the detector is working in the ABAX 2 system and the controller is connected to a SATEL alarm control panel). 2. Remove the screw fastening the detector cover (Fig. 3). -
Page 9: Specifications
SATEL ACMD-200 7. Lock the cover with a screw. 8. Press the test / reset button (Fig. 1). An alarm should be triggered. 9. Press again the test / reset button to clear the alarm. 6. Specifications Operating frequency band ....... 868.0 MHz ÷ 868.6 MHz / 915 MHz – 928 MHz Radio communication range (in open area) ACU-220 ...................... - Page 10 ACMD-200 SATEL Operating temperature range ..................0°C...55°C Maximum humidity ......................93±3% Dimensions ......................ø108 x 54 mm Weight ..........................153 g...
