• Easily Programmed Six-Digit User Code
• Simple 9-Volt Battery Replacement
• Fast One-Second Fingerprint Access, Sensor Quickly Reads Fingerprint in Any Position
and Automatically Unlocks
• Program up to Three User Codes and Five Associated Fingerprints per User Code, Total
of Fifteen Fingerprints
• User Code and Fingerprints Stored in Memory Within Safe Door Shielded, Along with
Internal Lock, From Drill Attacks by Ball Bearing Drill Protection Plate
• User Code Remains in Memory for Years Even if Battery or Keypad Destroyed or
Removed
• Lock's Memory Protected Inside the Safe and Cannot be Hotwired
• After Several Incorrect User Code/Fingerprint Attempts Lock Begins Lockout Delay
Period Disabling All Inputs to Keypad Delaying Further Tampering
OPERATING INSTRUCTIONS
Opening Safe for the First Time
SecuRam® ScanLogic™ Biometric Electronic Lock is shipped unlocked. Open the door by
rotating the hub on the front of the safe clockwise and pulling the safe door open. If the
hub seems stiff, insert a solid round wooden stick into one of the handle holes and turn
the hub clockwise to open. Then install the handles, if applicable.
Installing the Battery
Rhino Metals highly recommends using a 9-volt Duracell
battery with a "Use Date" of at least four years in the future.
1.
Unlock and pull the safe door open.
2.
To remove the keypad, push straight up from the bottom of the keypad until it
releases.
3.
Carefully pull the keypad away from the safe to prevent
damage to the wiring harness, revealing the battery
cavity.
4.
With the battery cavity accessible, install a new 9-volt
battery into the terminals and tuck the battery and wiring
harness back into the battery cavity.
5.
Slide the keypad back down onto the shoulder screws. Be
careful not to pinch the wiring harness on the screws.
6.
With the door open, test the operation of the lock several
times before closing and locking the safe.
SECURAM® SCANLOGIC™
BIOMETRIC ELECTRONIC LOCK
Model FPC-1808-II-MB
or Energizer
alkaline
®
®

Advertisement

loading
Need help?

Need help?

Do you have a question about the SCANLOGIC FPC-1808-II-MB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Securam SCANLOGIC FPC-1808-II-MB

Summary of Contents for Securam SCANLOGIC FPC-1808-II-MB

  • Page 1 OPERATING INSTRUCTIONS Opening Safe for the First Time SecuRam® ScanLogic™ Biometric Electronic Lock is shipped unlocked. Open the door by rotating the hub on the front of the safe clockwise and pulling the safe door open. If the hub seems stiff, insert a solid round wooden stick into one of the handle holes and turn the hub clockwise to open.
  • Page 2 Changing User Code and Fingerprint SecuRam® Electronic Lock user codes are set at the factory as 1-2-3-4-5-6 and preset fingerprint. For security purposes, immediately change the user code to a unique user code. The six-digit user code can be changed at any time. When creating a new user code, avoid using personal data such as birth dates, street numbers or phone numbers to keep valuables as secure as possible.

  • Page 3: Care And Maintenance

    If a mistake is made, wait 30 seconds and then repeat above steps. LOW BATTERY IS THE MOST COMMON CAUSE OF ELECTRONIC LOCK ISSUES. Repeated beeping during opening or any other unfamiliar occurrences indicates that the battery is low and needs to be replaced immediately. Lost User Code for Electronic Locks Most safes with electronic locks have their override user code on file at Rhino Metals.

  • Page 4: Troubleshooting

    TROUBLESHOOTING Common Issues Possible Solutions Replace the battery with a new 9-volt Duracell® or Energizer® alkaline battery with a “Use Date” of at least four years in the future. Any pressure on the side of the lock tang might prevent the lock from operating properly.
  • Page 5 WARRANTY CLAIMS AND REPAIRS Please carefully read the Limited Lifetime Warranty. It details the length of coverage and limitations for services and repairs. All Warranty services must be pre-authorized by Rhino Metals and require completing and providing proper documentation of ownership of the safe. If any Warranty questions, contact a local authorized dealer or Rhino Metals Tech Support.

  • Page 6: Limited Lifetime Warranty

    LIMITED LIFETIME WARRANTY Rhino Metals offers to the original Purchaser, a Limited Lifetime Warranty, covering defects in workmanship, material, damage by unlawful attempted or actual break-in, and fire. Warranty applies only to safes located in the United States and Canada, purchased at an authorized Rhino Metals safe dealer, and that have been used solely in residential applications.
  • Page 7 EXTENDED LOCK WARRANTY (SOLD SEPARATELY) Warranty must be purchased within 30 days of safe purchase to become valid. Rhino Metals offers to the original Purchaser, an Extended Lock Warranty, covering defects in workmanship and material on either electric or manual locks. Locks and electronic keypads carry a five-year Warranty for labor and parts.
