Securam SafeLogic Basic Operating Instructions

SafeLogic Basic
Operating Instructions (User)
Unlock and Code Change Functions.

Battery Installation.

Initially the keypad may not have a battery fitted.

To insert/replace the battery, release the latch of the battery
compartment by pulling lever downward, See Fig. 2.

Pull out the battery compartment at the bottom of the Entry Pad, See Fig. 3.

Take out the battery and replace with a new 9V alkaline battery (Duracell and Energizer brands
are recommended). Insert the battery into the compartment with the positive and negative
terminals orientated correctly. See Fig.4.

Put the battery compartment back into the entry pad. Push up the latch of the battery
compartment until it snaps closed. See Fig. 1.

How to open the lock.

The lock will be set on a default code of 1 2 3 4 5 6

Press the default code 1 2 3 4 5 6 in sequence (LED flickers and unit sounds Bi with each
number)
On final number lock gives a double LED flicker and sounds Bi Bi.

Wrong entry time penalty.

Entry of four consecutive invalid codes results in a 5-minute penalty time period. The unit beeps at 5
second intervals indicating that it is still in the penalty time period.

While the system is in penalty time, the Entry Pad buttons remain unresponsive.

Pressing buttons during penalty will not restart or lengthen the penalty time period. It will
continue to count through the 5 minute penalty time period.

While the system is in penalty time, removal of the batteries will interrupt the penalty time
countdown. Upon reinstallation of the batteries, the Entry Pad continues to count down until the
5 minute penalty time period expires.
