SafeLogic Xtreme Installa3on and Opera3on Instruc3ons
SafeLogic Xtreme - Electromechanical Redundant Safe Lock System - Instruc;ons
Please visit the website below by scanning the QR code with your smartphone or by typing in the
address below for video instruc3ons on SafeLogic Xtreme Install Instruc3ons.
Important:
1. Do not remove the back cover of the lock case.
2. Modifica3ons of the lock are not recommended and will void product warranty.
3. Use a brand new 9V ALKLINE baLery only. Recommend baLeries: Energizer
brand.
4. Note that the 4-wire cable connectors have lock-tabs aLached to ensure that the cable is
securely connected and locked into place. To prevent damage to this connector, it is required
to pinch the lock-tab when disconnec3ng the 4-wire cable connector from the socket.
5. Package consists of:
1. EC-1501A-X EntryPad.
2. XL-1501 Electromechanical Lock Body.
SECURAM Systems Inc.
hLp://goo.gl/3pZ16W
Doc. No. XU-EC1501A-X201222
or Duracell
TM
Page 1
TM

Advertisement

loading
Need help?

Need help?

Do you have a question about the SafeLogic Xtreme and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Securam SafeLogic Xtreme

Summary of Contents for Securam SafeLogic Xtreme

  • Page 1 SafeLogic Xtreme Installa3on and Opera3on Instruc3ons Doc. No. XU-EC1501A-X201222 SafeLogic Xtreme - Electromechanical Redundant Safe Lock System - Instruc;ons Please visit the website below by scanning the QR code with your smartphone or by typing in the address below for video instruc3ons on SafeLogic Xtreme Install Instruc3ons.
  • Page 2 7. DialRing Moun3ng Bolt: 4 PCS. Used to install the EntryPad to the front of the safe door. 8. Clear Plas3c Spindle Tube IMPORTANT: Do NOT use power tools to install the SafeLogic Xtreme. 1.0 Preparing to Install the DialRing and EntryPad Separate the DialRing from the EntryPad: Step 1: Pull up on the SpinDial release to disengage the electronics.
  • Page 3 SafeLogic Xtreme Installa3on and Opera3on Instruc3ons Doc. No. XU-EC1501A-X201222 2.0 Installing the DialRing Step 1: Locate t h e D i a l R i n g moun3ng holes and spindle hole (minimum 10mm Dia) on the safe door Step 2: Make sure the spindle hole is de-burred and has no sharp edges that could damage the cable.
  • Page 4 SafeLogic Xtreme Installa3on and Opera3on Instruc3ons Doc. No. XU-EC1501A-X201222 Step 7: Tighten the DialRing Moun3ng bolts (Part# M4 Bolt) to hold the DialRing in place. It is not necessary to securely 3ghten the Dial Ring Moun3ng bolts (Part# M4 Bolt), as the installa3on of the DialRing shall be adjusted during the next steps.
  • Page 5 SafeLogic Xtreme Installa3on and Opera3on Instruc3ons Doc. No. XU-EC1501A-X201222 Step 2: Take note of the 3 ports (holes) surrounding the spindle inser3on point on the lock cover as pictured below. These “Locator Ports” will be used to posi3on the cam inside the lock correctly for SpinDial access.
  • Page 6 SafeLogic Xtreme Installa3on and Opera3on Instruc3ons Doc. No. XU-EC1501A-X201222 Step 5: Now that the cam is oriented correctly, remove the spindle (Part# MSP-15A-6IN). Step 6: The spindle (Part# MSP-15A-6IN) has one end that is drill and tapped to receive the Spindle Bolt (Part# M4*16).
  • Page 7 SafeLogic Xtreme Installa3on and Opera3on Instruc3ons Doc. No. XU-EC1501A-X201222 Step 10: Remove the spindle bolt (Part# M4*16) and spindle (Part# MSP-15A-6IN) from lock case prior to cuqng. Carefully cut the spindle so that it will be flush to the lock cover.
  • Page 8 SafeLogic Xtreme Installa3on and Opera3on Instruc3ons Doc. No. XU-EC1501A-X201222 moun3ng bolts again and adjust the posi3on of the DialRing accordingly. 6.0 Install Electronic EntryPad Step 1: Install the 9V ALKALINE baLery in the back of the EntryPad. Embossed in the boLom of baLery compartment you will see the baLery orienta3on markings: “+”...

  • Page 9: Installa;On

    (Fig. 7) and close the SpinDial release. (Fig. 8) 8.0 Electronic Lock Opera;ng Instruc;ons The SafeLogic Xtreme comes with the user code set to the factory default of 1-2-3-4-5-6. 8.1 To Open the Lock with a Code Step 1: Press 1-2-3-4-5-6.
  • Page 10 If the lock does not open using the new code, repeat the change code process again. 9.0 Mechanical Lock Opera;ng Instruc;ons The mechanical combina3on of SafeLogic Xtreme preset to 50-50-50. 9.1 First SpinDial Combina;on Opening Step 1: Pull up on the SpinDial Release to disengage the electronics Step 2: Now rotate the SpinDial 4 full revolu3ons to the let (or counter clockwise) stop when you see 50 at the Dialing Index the fourth 3me.

  • Page 11: Change Index

    SafeLogic Xtreme Installa3on and Opera3on Instruc3ons Doc. No. XU-EC1501A-X201222 Step 3: Now rotate the SpinDial to the right un3l it comes to a stop (within one revolu3on) When the SpinDial comes to a stop the lock is open. Step 4: Turn your safe handle.
  • Page 12 SafeLogic Xtreme Installa3on and Opera3on Instruc3ons Doc. No. XU-EC1501A-X201222 Step 6: Now on the lock body (on the back of the safe door) locate the change key hole. Step 7: Insert the Change Key into the change key hole un3l the key reaches the boLom of the lock case.
  • Page 13 SafeLogic Xtreme Installa3on and Opera3on Instruc3ons Doc. No. XU-EC1501A-X201222 Step 14: Test this new combina3on to make sure that it works correctly, before closing the safe door. See Dialing a Mechanical Combina3on. Step 15: Commit the new combina3on to memory.
  • Page 14 SafeLogic Xtreme Installa3on and Opera3on Instruc3ons Doc. No. XU-EC1501A-X201222 Step 3: Connect the EntryPad to the DialRing and reconnect the cable to the lock. Step 4: Ater 3~ 5 seconds, remove the U-type tool from the reset holes. Step 5: The default codes will now operate the lock.
