INSTALLATION AND OPERATION MANUAL
9.6.4 SYSTEM TOOLS Page SNMP SETUP Section
Enable SNMP
Read Password
Engine ID
Enable SNMP trap Not enabled by default.
Trap Destination IP Destination IP address where the trap messages will be sent.
Community
Remember to select Apply if any changes were made.
9.6.5 SYSTEM TOOLS Page NTP SETUP Section
Select your Time Zone:
Current Router
Time
Proposed Router
Time
Enable NTP Client Not enabled by default.
Known Time
Server
Time server
Remember to select Apply if any changes were made.
9.6.6 SYSTEM TOOLS Page TELNET SERVER Section
Enable Telnet Server
Telnet server port
9.6.7 SYSTEM TOOLS Page SYSTEM SERVER Section
Enable Syslog
Logging IP/
Domain Name
Logging port
TECH SUPPORT: 1.888.678.9427
Not enabled by default
Password to query the device
Engine ID for the SNMP agent. Default is
800007e5BD00002704D000007c
Enter the SNMP community string
This is the time the node is set to. This will be updated and displayed
in the STATUS page by either setting to the browsing computer
system clock or by a connected NTP server.
This will display the system clock of the device that is browsing to the
node. If the Adjust button is pressed, The time displayed in this box
will overwrite the clock on the device.
Select a time server from the drop down list.
NOTE: The node will need to have access to the internet to connect to any
one of these servers.
Manually enter in a time server if the desired one is not in the Known
Timer Server list.
Enabled by default
Port 23 is the default
Not enabled by default
Enter in the destination IP address of the device to receive the system
log
Port 514 is the default. Port 514 is common for receiving UDP system
logs
NW3/NW4
