INSTALLATION AND OPERATION MANUAL
9.5.1 NETWORK SETTINGS Page LOCAL AREA NETWORK Section
LAN Mode
IP Address
Netmask
Gateway IP
DHCP Fallback IP This will be the address the web server will default to if it cannot
DHCP Mode
DHCP Start IP
Address
DHCP Stop IP
Address
DHCP Netmask
DHCP Gateway IP IP address for the network segment gateway that the DHCP sever will
DHCP Lease
Times
Remember to select Apply Settings if any changes were made.
9.5.2 NETWORK SETTINGS Page DHCP SERVER RESERVATIONS Section
Here one can assign IP addresses to specific MAC addresses. One the IP address and MAC
address has been entered, click the ADD button. Make sure the IP address assigned is within the
DHCP start and end address block.
Remember to select Apply Settings if any changes were made.
TECH SUPPORT: 1.888.678.9427
Embedded web server addressing mode. Options are static or
dynamic for an address from a local DHCP server.
For setting the static address for the embedded web server.
Static network mask
Static gateway IP address
establish communications with a DHCP server
This enables an option to make the node act as a DHCP server.
NOTE: Can only set DHCP server if the node is statically addressed. Once
the DHCP Server option has been selected, DHCP option fields below are
enabled for entry.
DHCP address block start address
DHCP address block stop address
DHCP Network mask that the DHCP sever will pass to the DHCP
clients
pass to the DHCP clients
Lease time for the DHCP addresses. Default is 1 hour or 3600
seconds.
NW3/NW4
INS_NW(3,4)_REV– 06/10/13 PAGE 30
