INSTALLATION AND OPERATION MANUAL
9.3.1 WIRELESS SETTINGS-AP Page BASIC WIRELESS SETTINGS Section
NOTE: Any settings changes made on this page will require the hitting Apply Settings button
then select Save.
Wireless Mode The user can select either Access Point or Client mode of operation.
Local AP-ESSID The SSID this AP will broadcast.
Country Code A country of operation can be selected from the pull down. NOTE: for the FCC version,
only United States will be in the list while countries participating in the ETSI harmonized
standards will populate this list for the ETSI version.
Wireless Profile Select either NA or NG operation. NA is 802.11a and 802.11n (5GHZ operation). NG is
802.11g and 802.11n (2.4GHz operation). NOTE – some models may only support the NA
(5GHz) option.
Channel The user can select the operation channel width. 20/40M lets the units determine the
Spectrum Width best channel width with the maximum 40MHz as an option under good RF conditions.
One may want to choose 20MHz for noisy or congested RF environments. Options
available are 20/40M, 20M, and 10M.
Guard Interval This represents the guard interval between packets. The options are Short and Long.
The Long option is recommended for links greater than 2Km in distance.
Channel Auto is enabled by default. When Auto is unchecked, the user can select from a number
Frequency of frequencies available from the drop down list. When Auto is checked and during
boot up, The AP will select the operational channel with least interference.
Select Button When pressed, a pop up screen comes up like the one below:
This allows the user to select which frequencies the AP will scan for during reboot and
when Auto mode is checked/enabled.
