INSTALLATION AND OPERATION MANUAL
9.4.1 WIRELESS SETTINGS-Client Page BASIC WIRELESS SETTINGS Section
NOTE: Any settings changes made on this page will require selecting the 'Save' pop up button
then the 'Apply Settings' button.
Wireless Mode The user can select either Access Point or Client mode of operation.
Remote AP-ESSID Remote Access point SSID can be entered here.
Site Survey When pressed, will generate a pop up screen showing all the potential APs that it can
Button connect to like the image below:
NOTE: If there is an AP you wish to connect to, just double click on the desired AP line this
window will close and auto populate the Remote AP-SSID box and the Remote AP-Lock to MAC
address box.
Country Code A country of operation can be selected from the pull down.
NOTE: For the FCC version, only United States will be in the list while countries participating in
the ETSI harmonized standards will populate this list for the ETSI version.
Wireless Profile Select either NA or NG operation. NA is 802.11a and 802.11n (5GHZ operation). NG is
802.11g and 802.11n (2.4GHz operation).
NOTE: Some models may only support the NA (5GHz) option.
Channel The user can select the operation channel width. 20/40M lets the units determine the
Spectrum Width best channel width with the maximum 40MHz as an option under good RF conditions.
One may want to choose 20MHz for noisy or congested RF environments. Options
available are 20/40M, 20M, and 10M.
Guard Interval This represents the guard interval between packets. The options are Short and Long.
The Long option is recommended for links greater than 2Km in distance.
Transmit Power This section will set the RF transmit power. The maximum RF power available will be
limited in software based on the gain of the integrated antenna and the region the unit
was programmed to operate in. The default will set the unit to maximum RF power and
here the user can reduce the RF power in case the RX RSSI levels on the remote unit
exceed 65.
Channel Scan List When enabled, the client will only scan the channels selected.
Select Channels When this button is pressed, a new client scan window will pop up shown below:
To Scan Button
Here the user can select which channels the client will scan. This can reduce link lock
times if the desired AP is fixed to a known frequency.
Remember to select Apply Settings if any changes were made.
