Jumpers
The purpose of the jumper is to set whether the board is a Main Node or Sub Node. If Main Node is selected, the
LTC4368 will close once appropriate voltage levels are detected. If Sub Node is selected, the LTC4368 will only
close if woken up by an upstream Main Node or Sub Node.
Jumper
1 and 2 (DEFAULT)
2 and 3

AD2437 SIO0 Routing ( JP6)

The AD2437 SIO0 jumper is used to select the routing of the AD2437 SIO0 signal. The default setting for the
jumper is pins 1 and 2.
Jumper
1 and 2 (DEFAULT)
2 and 3

AD2437 SIO1 Routing ( JP9)

The AD2437 SIO1 jumper is used to select the routing of the AD2437 SIO1 signal. The default setting for the
jumper is pins 1 and 2.
Jumper
1 and 2 (DEFAULT)
2 and 3

ADAU1452 CLK Select ( JP38)

The CLK Select jumper is used to select the CLK source for the ADAU1452 Main Clock. For Main Mode, jumper
must be between 1 and 2. For Sub Mode, it should be between 2 and 3. The default position is 1 and 2.
Jumper
1 and 2 (DEFAULT)
2 and 3

USBi SPI Chip Select ( JP42)

The USBi Chip Select jumper is used to select the SPI communication for the A
enable Chip Select of AD2437 to be connected to USBi SPI port. The default position is not connected. Please
ensure that PWM select jumper ( JP47) is open when configuring the USBi SPI Chip select jumper. The default
address id 0x6A.
3–6
Routing
Main Node
Sub Node
Routing
I2S SDATA_OUT0 from ADAU1452
PDM_DATA0
Routing
I2S SDATA_OUT1 from ADAU1452
PDM_DATA1
Routing
24.576 MHz Crystal Oscillator
AD2437 MCLK
2
B transceiver using USBi. This will
