Connectors
Connector Locations:
Figure 3-2: Connector Locations
Power Plug ( P1)
This powers up the board with a 24V supply. Power is required when the board is operating in both main and sub
mode.
Part Description
2.1 mm power jack
24.0VDC@3A power supply
Wire-to-Board Terminal ( P2)
3–2
DNP
DNP
Manufacturer
CUI
Mating Cable
CUI
Part Number
PJ-102AH
KTPS65-2430DT-3P-VI
TOP
BOTTOM
