This powers up the board with a wire to board supply. Power is required when the board is operating in both main
and sub mode.
Part Description
5.08mm power jack
24.0VDC discrete wires

SPDIF Optical Input ( P3)

The SPDIF Input connector is connected to the SPDIFIN on the ADAU1452. The SPDIF connection offers gala-
vanic isolation for equipment saftey.
Part Description
RCA Jack
Standard SPDIF cable (non optical)

SPDIF Optical Output ( P5)

The SPDIF Output connector is connected to the SPDIFOUT on the ADAU1452. The SPDIF connection offers
galavanic isolation for equipment saftey.
Part Description
RCA Jack
Standard SPDIF cable (non optical)

ADAU1452 AUX ADC Connector ( P8)

2
A B ( P22 and P10)
P10 is used to connect towards the sub board and P22is used to connect towards the main board. These connectors
allow the AD2437 on the eval board to communicate with other A
Part Description
RJ45 - Ethernet
Ethernet cable assembly
EVAL-AD2437A1MZ Manual
Manufacturer
Weidmuller
Mating Cable
Manufacturer
CUI
Mating Cable
Manufacturer
CUI
Mating Cable
Manufacturer
Amphenol ICC
Mating Cable
Part Number
1716020000
Part Number
RCJ-011
Part Number
RCJ-011
2
B devices on the bus.
Part Number
RJE73-188-00210
Connectors
3–3
