Chapter 1: Introduction

1.1 Specifications

Model
Model with RFID
Printing Mode
Max Printing Speed
Max Printing Width
Max Printing Length
MPU
GPU
Memory
HEAT TM Level
①
RFID Encoder
Media Roll
Minimum Label
Length
Media Thickness
Ribbon
Media Sensor
TX2 Exp
TX2r Exp
Direct Thermal and Thermal Transfer
16 ips (406.4 mm/s)
4.09" (104 mm)
196" (500 mm)
64-bit, quad Arm® Cortex®-A53 core, maximum operating frequency 1.8
GHz
GC NanoUltra 3D (1 shader) &GC320 2D OpenGL ES 2.0
2GB DDR4 RAM, 8GB managed NAND flash
I
Supports UHF EPC Gen 2, ISO 18000-6C protocols
(Only available for RFID models)
Maximum Media Width: 4.56" (116 mm)
Minimum Media Width: 0.39" (10 mm)
Maximum Outer Diameter: 8" (203.2 mm)
Inner Diameter: 1.5" (38 mm) / 3" (76.2 mm)
Tear-off: 0.2" (5 mm)
Cutter: A150/A400: 0.79" (20 mm)
Regular Barcode Label Printer and Regular RFID Label Printer: 0.0024" ~
0.012" (0.06 ~ 0.305 mm), including liner
Mount-on-Metal RFID Label Printer
liner
Maximum Ribbon Length: 1968' (600 m)
Maximum Ribbon Width: 4.65" (118 mm)
Maximum Outer Diameter: 3.31" (84 mm)
Inner Diameter: 1" (25.4 mm)
Ink side: both In and Out
Upper reflective: detects black marks on print side
Lower reflective: detects black marks on back side
Transmissive: detects gaps, notches, holes
TX3 Exp
TX3r Exp
12 ips (304.8 mm/s)
4.16" (105.7 mm)
: 0.063" (1.6 mm) max., including
②
Chapter 1: Introduction
TX6 Exp
TX6r Exp
6 ips (152.4 mm/s)
4.16" (105.6 mm)
4
