Johnson Controls IQ4 NS Installation Manual page 154

SPECIFICATIONS - LATIN AMERICA (EXLUDES BRAZIL, COSTA RICA)
Items
Microphone MEMs x 1
Tamper Tamper Switch
Battery Type 18650
Buttons Hard Button
Mechanical Dimension
AC/DC External Plug-in
Power Supply
Adapter
Mount Back Plate
Argentina
Chile
Certification
Columbia
Uruguay
Operational
Temperature
Storage
Parameters
1 MEMs (micro electro mechanical system) Microphone
Dual Panel and wall tamper switch with spring release
Lithium Ion 3000mAh. Ningbo Veken Battery Co., Ltd, Model VT27 or Icon Energy System Co. Ltd,
Model IAN034NA
Single wake/sleep button used for sleep/wake, hard reboot, and clean screen cancel
6.1"H x 7.5"W x 1"D (155mm x 191mm x 26mm)
Output: 7vDC (⎓) 1000mA CC, or 7vDC (⎓) 1.5A CC, Input 100-240VAC 50/60Hz. Adapter evaluated
at 120vAC for UL/cUL
SmartMount wall mount included. SmartMount table stand or sold separately.
Reserved
0 to 49C, up to 93% rela;ve humidity, indoor, dry ordinary loca;ons use only
-20 to 50C
QOLSYS CONFIDENTIAL AND PROPRIETARY
PAGE 154 OF 158
IQ4 NS
