INSTALLING THE PANEL
WALL MOUNT
Note: For UL/ULC Commercial Burg installations (UL2610/ULC-S304 Security
Level II compliant) and EN Grade 2 installations use only wall mount option
This product when installed as per these instructions does not present the risk of fire, electric shock, or injury to persons.
1
1
2
3
1
2
1. Mount the backplate to the
wall using flat head screws* and
Connect the power supply to
appropriate wall anchors if
1
the barrel jack on the back of
needed, ensuring it is level.
the panel.
2. If using the model with the
1. Latch the top of the IQ4 NS
legacy security radio, in the
onto the SmartMount
provided hole on the right hand
backplate.
side of the backplate drill a 1/4"
1. With a small phillips 1. With a small phillips
hole in the wall and feed the 2. Swing the panel down
screwdriver, undo the screwdriver, screw in the
white RF antenna into the wall. towards the backplate and
locking screw from the back locking screw from the
press firmly against the wall.
of the panel and remove the bottom of the panel to
3. A screw is required in break-
SmartMount backplate. secure it to the wall.
away wall tamper for UL 2610
and EN Grade 2 installations.
*Screws shall be a minimum of 1" in length (25.4mm), size #6 (M3.5)
