Locating components in the vehicle
1- To gain access to the SLP connector, remove metal clip to remove the white plastic housing.
Steering Lock Connector
2. Remove white
1. Remove
plastic housing
metal clip
2- Move the white plastic housing over enough to access the SLP cnnector.
Steering Lock
connector
7
403.TL15 1.15 2020 Toyota RAV4 (Smart Key)
©2023 Directed. All rights
