Machine description – quick overview
Front view
4
Machine description – quick overview
4.1
Front view
Item
Symbol Description
1
2
3
4
5
6
7
8
14
0
Carrying handle
Signal light, Functional error
On when excess temperature detected
Main switch, machine on/off
Welding voltage step switch
To set the welding voltage
Cooling air inlet
Connection socket, workpiece lead
"Hard" choke tapping
Connection socket, workpiece lead
Choke tapping "soft"
Conveyor rolls, guide castors
Figure 4-1
099-005167-EW501
29.06.2010
