Operating manual Ruby
Fig. 76: Taking out inspection blank
Fig. 77: Removing the front cladding
10) Loosen nuts (1).
11) Take out inspection blank (2) and gasket (3).
12) Clean interior space with a vacuum cleaner.
13) Repeat these steps for the other two inspection blanks
14) After cleaning, attach and install all parts again.
1 2 5 4 5
15) Loosen the screws of the front cladding and lift off the
EN
(4+5).
cladding.
14 | Maintenance
