Flashforge Adventurer 3 Pro 2 User Manual page 8

Terms
Build Plate The surface on which the Adventurer 3 Pro 2 builds an object
The black tape that covers Adventurer 3 Pro 2's build plate so
Build Tape
that the object can stick to the build plate well
The dimensions of the space into which 3D prints can be
Build Volume
produced. The largest build volume is 150*150*150mm.
The integral extruder assembly is installed on X-axis.
Extruder The extruder draws the filament from the filament spool,
melts it and extrudes it through the nozzle into the build plate.
Also called 'print head', which is located at the bottom
Nozzle
of the extruder where heated filament is squeezed out.
Cooling Fan To cool the outer assembly of the extruder and gear motor
A specific box for placing Flashforge filament, which is
Filament Cartridge
located on the right of the printer.
A white plastic tube that guides the filament from the
Filament Guide Tube
filament box to the filament intake
An opening located at the top of the extruder
Filament Intake
A solid adhesive used for making the model stick to the
Solid Glue Stick
build plate firmly
05
