Vbase
Vamp
Overshoot
Preshoot
RiseTime
Fall Time
+Width
-Width
+Duty
-Duty
DelayA B
DelayA B
To measure the frequency of CH1 with MEAS SET 1 and the frequency of CH2 with MEAS
SET 2, perform the following steps:
Press the MENU key; the function menu will appear on the right side of the screen
1.
Press the MENU ▲ or MENU ▼ key to select MEAS SET 1. Five (5) selectable
2.
options will then appear at the bottom of the screen
3. Press the F1 key to select the frequency measurement of CH1. The measurement
window will appear red in color and show the frequency of CH1
Press the MENU ▲ or MENU ▼ key to select MEAS SET 2. Five (5) selectable
4.
options will then appear at the bottom of the screen
5. Press the F4 key to select the peak-to-peak value of CH2. The measurement
window will appear blue in color and show the peak-to-peak value of CH2
CH1 Measure the Vbase of CH1
CH2 Measure the Vbase of CH2
CH1 Measure the Vamp of CH1
CH2 Measure the Vamp of CH2
CH1 Measure the Overshoot of CH1
CH2 Measure the Overshoot of CH2
CH1 Measure the Preshoot of CH1
CH2 Measure the Preshoot of CH2
CH1 Measure the RiseTime of CH1
CH2 Measure the RiseTime of CH2
CH1 Measure the Fall Time of CH1
CH2 Measure the Fall Time of CH2
CH1 Measure the +Width of CH1
CH2 Measure the +Width of CH2
CH1 Measure the -Width of CH1
CH2 Measure the -Width of CH2
CH1 Measure the +Duty of CH1
CH2 Measure the +Duty of CH2
CH1 Measure the -Duty of CH1
CH2 Measure the -Duty of CH2
CH1 Measure the DelayA B
CH2
Measure the DelayA B
CH1 Measure the DelayA B
CH2
Measure the DelayA B
47
of CH1
of CH2
of CH1
of CH2
