This mode is only applicable to simultaneous CH1 and CH2 measurements. The X-Y
format plots the CH1 input as X-axis and CH2 input as Y-axis. This display mode is
convenient for viewing the phase relationship between CH1 and CH2; if the
oscilloscope does not detect triggering the data appear in light spots.
Description of Control Keys:
■ The CH1 VOL and CH1 ZERO keys for CH1 are used to set the horizontal
scale and position.
■ The CH2 VOL and CH2 ZERO keys for CH2 are used to set the vertical
scale and position continuously.
The following functions are not available in the XY display mode:
■ Reference or digital value waveform
■ Cursor
■ Time base control
■ Trigger control
S W
TORING AVEFORMS
The oscilloscope can save four (4) waveforms that can be displayed on the screen along
with the present waveform. The recalled waveforms cannot be adjusted.
The waveform Store / Recall menu is described in the following Table.
Function menu Setups
Source CH1
CH2
MATH
WAVE A, B, C and
D
Save
Show ON
OFF
To save a CH 1 waveform in address A, perform the following steps:
Description
Select the signal source of the waveform to save
(the waveform to save must be on the display)
Select the memory address for saving or recalling
data
Store the waveform of the selected signal source
into the selected address
Set ON to display the waveforms stored in
address A, B, C or D. Choose OFF to exit this
feature.
