Module programming

Refer to "LED diagnostics and troubleshooting" for more information and for troubleshooting purposes.

Method 2 (using 2 keys)

Ensure vehicle is in a safe location and cannot move forward during programming. For
1
vehicles equipped with a manual transmission, make sure the gearshift lever is in the neutral
position.
Wait until the LED turns ON solid red.
2 Note: For Convenience-Only installations without remote start) press the programming button
five times (5x).
The LED turns on solid orange.
Insert the first key and turn it to the ON position.
1.
3
Wait until the security light turns OFF, then remove the key.
2.
The LED starts flashing green.
Within 3 seconds, but no more than 10 seconds, insert the second key, and turn it to
1.
the ON position.
4
Wait until the security light turns OFF, then remove it.
2.
The LED starts flashing orange.
Press and hold the module programming button, then apply (+) 12V to the vehicle ignition
5
wire with a jumper wire (keep holding the programming button).
The LED turns ON solid green for 3 seconds, then turns OFF.
6
Release the programming button once the module has been successfully programmed.
You have successfully completed the module programming sequence.
