TOSHIBA Bar Code Printer
BA400 Series
Key Operation Specification
st
1
Edition:
February 26, 2019
nd
2
Edition
May 16, 2019
rd
3
Edition
Jul 12, 2019
th
4
Edition
Aug 09,2019
th
5
Edition
Oct 02, 2019

Advertisement

Table of Contents
loading

Related Manuals for Toshiba BA400 Series

Summary of Contents for Toshiba BA400 Series

  • Page 1 TOSHIBA Bar Code Printer BA400 Series Key Operation Specification Edition: February 26, 2019 Edition May 16, 2019 Edition Jul 12, 2019 Edition Aug 09,2019 Edition Oct 02, 2019...

  • Page 2: Table Of Contents

    Table of Contents Page SCOPE ............................1 OUTLINE ............................ 1 OPERATION PANEL ........................1 OUTLINE OF EACH MODE ......................2 ONLINE MODE ..........................2 Threshold setting mode ........................2 RFID Analyze mode ........................2 Information mode ..........................2 USER MODE ..........................2 SYSTEM MODE ..........................
  • Page 3 LIST BOX WITH SCROLLBAR ....................32 VALUE SETTING SCREEN ......................35 INFORMATION SCREEN ......................37 SENSOR ADJUSTMENT SCREEN ..................... 38 TEMPERATURE DISPLAY SCREEN..................39 SYSTEM MODE ........................40 OUTLINE OF THE SYSTEM MODE .................... 40 REFLECTING THE SYSTEM MODE SETTINGS TO THE PRINTER ........41 RESET ............................
  • Page 4 8.5.34 PEEL OFF TORQUE ........................91 TEST PRINT ..........................92 8.6.1 PRINT CONDITION ........................92 8.6.2 SLANT LINE (1DOT) ........................94 8.6.3 SLANT LINE (3DOT) ........................95 8.6.4 CHARACTERS ..........................96 8.6.5 BARCODE ............................ 97 8.6.6 NON-PRINTING ..........................97 8.6.7 FACTORY TEST ...........................
  • Page 5 11.3 Auto Configuration File ....................... 149 11.3.1 Format ............................149 11.3.2 Model Information ........................149 11.3.3 Display Message ......................... 149 11.3.4 Firmware File to be downloaded ....................149 POWER SAVE FUNCTION ....................150 COPYRIGHT©2019 TOSHIBA TEC Corporation All rights reserved...

  • Page 6: Scope

    1 SCOPE This specification describes key operations using the keys and the LCD of the BA400 series general-purpose bar code printers. 2 OUTLINE Key operations are different depending on the printer mode: Online mode in which operations are carried out through the keys and error messages are displayed while the printer is connected to the host such as a PC, and the system mode in which self-diagnosis and setting of various parameters are performed.

  • Page 7: Outline Of Each Mode

    4 OUTLINE OF EACH MODE This chapter describes the outline of each mode supported by the printer. Refer to each chapter for detailed information. Also, in the case of operation using a USB memory, it is not necessary to insert a USB memory in advance and it may be inserted immediately before the operation to be used.

  • Page 8: System Mode

    4.6 SYSTEM MODE This mode is mainly used by service persons or the production department staff for adjustment of the printer before shipment. The system mode contains the menus which might be changed not so frequently. In addition to the parameter setting and fine adjustment menus common to the User System Mode, there are sensor adjustment, interface, RFID, RTC and BASIC setting menus.

  • Page 9: General View Of Key Operation

    5 GENERAL VIEW OF KEY OPERATION [Power OFF] Power on Online mode [FEED] key Feed one label. [RESTART] key [PAUSE] key Pause state Hold down the [PAUSE] key for a few seconds. Threshold setting mode Hold down the [FEED] key for a few seconds.
  • Page 10 <1>EXIT <2>SET PARAMETERS <3>DETECTION LEVEL <4>SYSTEM TOOLS ▼ System mode SYSTEM MODE V1.0 ▲ <0>RESET <1>DIAGNOSTIC <2>SET PARAMETERS <3>TEST PRINT ▼ Download mode DOWNLOAD MODE Waiting for data... □□□□□ Auto configuration mode USB TO PRINTER Config file test TOSHIBA tec...
  • Page 11 Notes: 1. To enter the download mode, system mode or auto configuration mode, keep holding down the specified key until each menu is shown. 2. Power off When the power of the printer is turned off(Enter Power SW key), the ONLINE and ERROR LEDs synchronously flashes (ON: 250ms, OFF: 250ms).

  • Page 12: Online Mode

    6 ONLINE MODE KEY FUNCTION The printer behavior is not guaranteed when undefined key is operated. 6.1.1 Online Mode Screen Function (1) Feed one piece of media to eject one piece of media. [FEED] Use the media to feed to the print start position. If printing is attempted with the media improperly positioned, print data is not printed at the correct position.

  • Page 13: Help Screen

    6.1.2 Help Screen Function (1) Return the page to the previous help message. [FEED] (2) Ends help message screen. (1) Ends help message screen and restart. [RESTART] (1) Advance page to next help message. [PAUSE] (2) Ends help message screen. 6.1.3 Manual Threshold Setting Screen Function...

  • Page 14: Online Mode Screen

    When the power switch is pushed in, the LCD backlight turns on. When the entire LCD glows, release the power switch. After about 3 seconds, the following display appears. After that, when the startup process is complete, the display will be online. BA400 Series Initializing... 6.4.1 Online Mode Screen Example...

  • Page 15: Icon

    (Note): 1. Whether to display or hide the 1 and 4 lines of online mode screen can be selected in the system mode. 2. Refer to Section “6.4.2 Icon” for details on icon display. (*1) The number of labels printed is the cumulative number of labels printed after a printer is powered on. Number of labels printed reset to zero when the printer is turned on.
  • Page 16 OFF: No connection ON: Connecting to an access point Flashing: Roaming (*1) Bluetooth Connection Icon Displayed Bluetooth connection status OFF: Non Connection Available Connection Connection Bluetooth Mode Icon Displayed Bluetooth Auto Re-conncetion Mode OFF: Printer is not Bluetooth Auto Re-conncetion Mode : ON : Bluetooth Auto Re-conncetion Mode Data transmission icon Appears when a print job is present.

  • Page 17: Online Mode Screen Transition And Operation Example

    6.4.3 Online Mode Screen Transition and Operation Example BA400T-T V1.0 ONLINE PRINTED 000000 IP:192.168.010.020 Idling or normal issuing When the [RESTART] key is pressed, (TO DO)　123 the printer resumes printing if there is When the [PAUSE] key PAUSE remaining data to print. is pressed while printing: When printing is in progress, it is stopped.

  • Page 18: Help Screen

    6.5 HELP SCREEN 6.5.1 Explanation of Help Screen When “Help” is displayed at the lower right of the online mode screen, pressing the [PAUSE] key causes a help message to be shown. The help message is displayed on the upper four lines. When the message exceeds four lines, the up and down arrows are shown on the scrollbar on the left, and the hidden lines can be displayed by scrolling down.

  • Page 19: Help Screen Transition And Operation Example

    6.5.2 Help Screen Transition and Operation Example The help screen consists of three pages, which are Help 1, Help 2 and Help 3. Help 1 shows the details of the error, Help 2 shows a troubleshooting, and Help 3 shows how to recover from the error.

  • Page 20: Manual Threshold Setting

    MANUAL THRESHOLD SETTING 6.6.1 Outline of Threshold setting When a label stock is printed, the printer automatically corrects the print position by detecting gaps between the labels by using the transmissive sensor to maintain a constant print position. However, when preprinted label stock is used, print positions may not be detected correctly depending on ink type used for preprints.

  • Page 21: Threshold Setting Operation Example

    6.6.2 Threshold Setting Operation Example 1. Online mode: Online state BA400T-T V1.0 ONLINE PRINTED 000000 IP:192.168.010.020 ↓ Press the [PAUSE] key. 2. Online mode: Pause state PAUSE ↓ Hold down the [PAUSE] key for 3 seconds. SELECT MEDIA SENSOR 3. Threshold setting: Move the cursor with the [FEED] or ▴...
  • Page 22 1）REFL.(PRE-PRINT) 6b. Details of the r esult Peak :　3.7V Threshold :　2.7V Baseline :　1.3V ◀Result Adjust▶ ↓ Press the [PAUSE] key. THRESHOLD <REFL.> 6c. Threshold fine Operation is same as 8.7.3 adjustment THRESHOLD LEVEL ( 0.0 4.0 V) Press any of the [PAUSE] key. 1）REFL.(PRE-PRINT) 6d.
  • Page 23 The threshold setting judgment result is indicated with one of the following icon types. Display example Icon name Explanation OK (Mid.) Print position is detectable with the media sensor. Threshold is at the midpoint between the peak and the baseline. OK (High) Threshold is near the peak voltage, so detection of a gap/black mark may fail if the difference between the...
  • Page 24 (9) While the result of fine adjusted threshold setting is shown, pressing the [FEED] key returns the screen to the threshold fine adjustment screen and pressing the [PAUSE] key shows the details of the result. (10) During a threshold setting, the media is fed at the same speed with that for the previous issue. (11) Canceling from the threshold setting screen You can change to the PAUSE screen by pressing the [FEED] key + [PAUSE] key from the threshold setting screen.

  • Page 25: Rfid Analyze Mode

    6.7 RFID Analyze Mode 6.7.1 Outline of the RFID Calibration RFID Analyze is a function to automatically determine the distance to the optimum write/read position and the AGC value by RFID Analyze Tool. LCD will show “RFID ANALZE MODE” when printer is entered RFID Analyze Mode by RFID Analyze Tool. RFID Analyze Mode is below behavior.

  • Page 26: Information Mode

    INFORMATION MODE 6.8.1 Outline of the Information Mode In the information mode, the total feed amount counted during feed and printing operations is displayed on the LCD in units of centimeter and inch, and printed on request. The feed amount is counted at the end of feed or printing, and saved in the non-volatile memory. Notes: (*1) 1.

  • Page 27: Information Mode Operation Example

    6.8.2 Information Mode Operation Example [Online mode] BA400T-T V1.0A 1. Normal state ONLINE PRINTED 000000 IP:192.168.010.020 ↓ Press the [PAUSE] key. [Online mode] 2. Pause state PAUSE ↓ Hold down the [FEED] key for 3 seconds. BCP COUNTER [Information mode] 477984cm Pressing [RESTART]...

  • Page 28: Information Mode Print Sample

    6.8.3 Information Mode Print Sample <Print sample> Max. number of digits: 74 mm, Center-aligned TOTAL COUNTER LIST MM-dd-yyyy hh:mm xxxxxxxxxxxxxxxx S/N:zzzzzzzzzzzzzzzzzzzzzzzzzzzzzzzz PRINTER aaaaaaaaacm bbbbbbbbb.binch Max. number of digits: 74 mm Effective print width <Print data> Item Information Range 1st line Title TOTAL COUNTER LIST 2nd line...

  • Page 29: Lcd Messages And Led Indications

    LCD MESSAGES AND LED INDICATIONS Acceptance of Restoration by LCD Message Status Request indications the [RESTART] line Printer status and Reset (English) Command ERROR Yes/No LINE Yes/No  ● In the online mode In the online mode  ● ONLINE (Communicating) In the online mode with a ribbon ...
  • Page 30 ▪ A ribbon has end. ▪ An abnormal condition occurred with the sensor for determining the ●  11 RIBBON ERROR torque of the ribbon motor. ▪ A ribbon jam occurred. ▪ The ribbon has been torn. ▪ The ribbon has not been set. FRONT COVER Printer will print with Front Cover...
  • Page 31 When any abnormal operations as below are performed, a system error occurs. (a) Command fetch from an odd address (b) Access to the word data from a place other than the boundary of the word data (c) Access to the long word data from a place other than the boundary of ●...
  • Page 32 Notes 1. When the ribbon near end detection is enabled, the error LED blinks at a 1-second interval (ON for 500 msec. OFF for 500 msec.) while the printer is in a ribbon near end state. 2. When 25 INPUT PASSWORD or 26 PASSWORD INVALID is displayed in the password input to enter the user mode, the status returned by the status request command is undefined.
  • Page 33 LCD message (2 line) English Germany French ONLINE PRETE ONLINE Kopf offen. TÊTE OUVERTE HEAD OPEN PAUSE PAUSE PAUSE Kommunikations-Fehler ERREURS DE COMMUNICAT COMMS ERROR PAPIERSTAU BOURRAGE PAPIER PAPER JAM Messer Fehler ERREUR MASSICOT CUTTER ERROR Kein Papier. PAS DE PAPIER NO PAPER Kopf offen.
  • Page 34 Dutch Spanish Japanese IN LIJN PREPARADA オンライン PRINTKOP OPEN. CABEZAL ABIERTO ヘッドオープン PAUZE PAUSA ポーズ COMMUNICATIE FOUT ERROR DE COMUNICACION 通信エラー PAPIER STORING. ATASCO DE PAPEL 紙送りエラー FOUT SNIJMES ERROR DE CORTADOR カッターエラー GEEN PAPIER SIN PAPEL 紙がありません PRINTKOP OPEN. CABEZAL ABIERTO ヘッドオープン...
  • Page 35 Italy Portuguese Chinese On Line PREPARADA ONLINE Testina Aperta CABECA ABERTA 打印头打开 PAUSA PAUSA 暂停 Errore Seriale ERRO DE COMUNICACAO 通讯错误 Carta inceppata PAPEL ENCRAVADO 卡纸 Errore Taglierina ERRO DE CORTADOR 切刀错误 Manca Carta SEM PAPEL 缺纸 Testina Aperta CABECA ABERTA 打印头打开...
  • Page 36 Korean Turkish Polish 온라인 ONLINE ONLINE 헤드 열림 Kafa açı k OTWARTA GŁ OWICA. PAUSE PAUSE PAUZA 통신 에러. İ LETİ Ş İ M HATASI BŁ Ą D COMMS 용지 잼 Kağ ı t sı kı ş ması ZACIĘ CIE PAPIERU 커터...

  • Page 37: Display Pattern And Key Operation For System Mode And User System Mode

    7 DISPLAY PATTERN AND KEY OPERATION FOR SYSTEM MODE AND USER SYSTEM MODE 7.1 LIST BOX WITH SCROLLBAR The list box is used for displaying the menus or items to be selected. It is comprised of the following parts. SYSTEM MODE C1.6 Title ▲...
  • Page 38 Key function (value setting display) Substitute Key Function [FEED] + [RESTART] Returns to the upper-level menu without saving changes. [PAUSE] Saves the changes and returns to the upper-level menu. [RESTART] Moves the cursor upward. When the cursor is positioned at the top of the list, it scrolls from the top to the bottom.
  • Page 39 Movement of the cursor in screen scroll The cursor moves in the following way with a press the [FEED] or [RESTART] key. The following table shows the example of press the [FEED] key. The [RESTRT] key functions in the same way. Display Key operation Explanation...

  • Page 40: Value Setting Screen

    VALUE SETTING SCREEN The value setting screen is used for setting a value by increasing or decreasing it. It is comprised of the following parts. Display example FEED ADJ. Title Setting range +0.0 Setting value (-50.0 - +50.0)mm Notes: 1. The currently programmable item is highlighted. 2.
  • Page 41 Key operation (Setting screen with multiple fields (horizontal)) Substitute Key Function [FEED] + [RESTART] Return to the upper-level menu without saving changes. [PAUSE] Save the changes and returns to the upper-level menu. [RESTART] Increases the setting value by specified step. When the setting value reaches the maximum, it returns to the minimum value and increases.

  • Page 42: Information Screen

    7.3 INFORMATION SCREEN The information screen is used when there is no settings are configured. It is comprised with the following: Display example Title Information Display Scroll RFID tag read Key function Substitute Key Function [FEED] + [RESTART] Displays the upper-level menu. [PAUSE] Displays the upper-level menu.

  • Page 43: Sensor Adjustment Screen

    7.4 SENSOR ADJUSTMENT SCREEN The sensor adjustment screen is used only when the level of the media sensors on the printer is required to be adjusted. It is comprised with the following : Display example REFLECTIVE SENSOR Title 4.3V Message Sensor level Set a blank label [ENTER] for 3sec...

  • Page 44: Temperature Display Screen

    7.5 TEMPERATURE DISPLAY SCREEN Temperature display screen is used only for displaying the print head temperature and ambient temperature. It is comprised with the following : Display example TEMPERATURE Title Print head temperature THERMAL HEAD 20℃ OPEN-AIR 13℃ Ambient temperature Display Display of temperatures TEMPERATURE...

  • Page 45: System Mode

    Turn on the printer while holding down the [FEED] and [PAUSE] key at the same time. When the following display appears, you can enter system mode by releasing your hands from the [FEED] key and [PAUSE] key. BA400 Series Initializing... entering SYSTEM MODE 2.

  • Page 46: Reflecting The System Mode Settings To The Printer

    Outline of the top menu <0>RESET Restart the printer. <1>DIAGNOSTIC Perform self diagnosis, print out the result, check for the print head broken elements. <2>SET PARAMETERS Set the parameters for printer functions <3>TEST PRINT Test print quality by printing slant lines, characters and barcodes. <4>SENSOR Display the ambient temaprature and print head temparature, and adjust each level of the media sensors.

  • Page 47: Maintenance Counter

    8.4.1 MAINTENANCE COUNTER The following table shows the menu structure from the top menu of the system mode to MAINTENANCE COUNTER. Menu item <1>DIAGNOSTIC MAINTENANCE COUNTER THERMAL TRANSFER PAPER CUTTING DIRECT THERMAL PAPER CUTTING DISPLAY COUNTER ADJUSTMENT(PC) STORAGE AREA USB SERIAL NUMBER WLAN AUTHENTICATION RFID TAG COUNT Notes:...
  • Page 48 PRINT TYPE C1.6 1. Select either THERMAL TRANSFER or DIRECT ▲ THERMAL. THERMAL TRANSFER 2. Press the [PAUSE] key. DIRECT THERMAL DISPLAY 3. PAPER CUTTING? Menu is displayed. ▼ PAPER CUTTING? C1.6 1. Select YES or NO. ▲ 2. Press the [PAUSE] key. 3.
  • Page 49 8.4.1.1 Maintenance Counter/Parameter Settings Print Contents ISSUE CTRL SENSOR [COMMAND] << COUNTER >> MODE [COMMAND] TOTAL FEED 3.7km [QM] SPEED [COMMAND] FEED 2.4km RIBBON [COMMAND] FEED1 1.3km ROTATION [COMMAND] FEED2 0.0km STATUS [COMMAND] FEED3 0.0km << PANEL >> FEED4 0.0km LANGUAGE [ENGLISH] PRINT...
  • Page 50 << BLUETOOTH >> BLUETOOTH [ON] DEVICE NICKNAME [TOSHIBA TEC BT] BD ADDRESS [00:16:A4:08:CF:8D] FACTORY TEST [OFF] INQUIRY [EVERY] SECURITY [SPP] SCAN INTERVAL [2048] SCAN WINDOW [36] AUTO CONNECT [OFF] SSP AUTH [JUST WORKS] << RFID >> MODULE TYPE [NONE] TAG TYPE...
  • Page 51 Print condition: Print method User setting Sensor type None Speed 4 ips Print count Issue mode User setting << COUNTER >> Item Description Range Counting condition TOTAL FEED [Description] Total label distance covered (cannot be cleared) [Range] 0.0 to 3200.0 km [Counting condition] Counted when the media feed motor is driven to feed or print the media.
  • Page 52 << ADJUST >> Item Description Remarks [PC]/[KEY] FEED Feed amount fine adjustment -50.0mm to +50.0mm -50.0mm to +50.0mm Cut position (or strip position) fine adjustment BACK -9.9mm to +9.9mm Reverse feed amount fine adjustment TONE (T) -10 to +10 step Print density fine adjustment (Thermal transfer print mode) TONE (D)
  • Page 53 << PARAMETER SETTINGS >> Item Description Value to be printed MEDIA LOAD [ ] [Description] Media feed to the print start position [Values to be printed] OFF: Disabled. STD: Feeds the detected gap/mark to the print start position. ECO: Feeds a gap/mark positioned between the print head and the media sensor, if any, to the print start position.
  • Page 54 [Description 1] Character code selection [Value to be printed 1] PC-850 PC-852 PC-857 PC-8 PC-851 PC-855 PC-1250 PC-1251 PC-1252 PC-1253 PC-1254 PC-1257 LATIN9 Arabic PC-866 UTF-8 [Description 2] Character “0” selection [Values to be printed] with slash Ø: without slash CTRL CODE [ ] [Description] Control code type [Values to be printed]...
  • Page 55 [Values to be printed] 20 to FF (Hex. code) AUTO HEAD CHK [ ] [Description] Whether to perform automatic print head check [Values to be printed] OFF: Not performed. Performed. WEB PRINTER [ ] [Description] Whether to use the printer as a web printer [Values to be printed] OFF: Not used.
  • Page 56 rsv7: (Reserved7): Reserved [Note] This item is reflected when the printer is turned OFF / ON. ENERGY TYPE (D) [ ] [Description] Energy level applied to the print head in thermal direct mode [Values to be printed] NORM: General-purpose HIGH: : High LOW:: SA1 SA Type1:...
  • Page 57 1 km to 3200 km PEEL OFF TRQ Description] Setting Peel off torque [Values to be printed] Weak Strong KB I/F [Description] Setting Key Board I/F [Values to be printed] OFF: Disable KB70: Use KB70 ISSUE CTRL [] [Description] Issuance control settings [Values to be printed] SENSOR: Sensor...
  • Page 58 << PANEL >> LANGUAGE [ ] [Description] Selection of a language for displaying LCD messages [Values to be printed] ENGLISH: English GERMAN: German FRANCH: French DUTCH: Dutch SPANISH: Spanish JAPANESE: Japanese ITALIAN: Italian PORTUGUESE: Portuguese Si.CHINESE: Simplified Chinese KOREAN: Korean TURKISH: Turkish POLISH:...
  • Page 59 [Description] External character storage area size [Values to be printed] 0KB to 3072KB BASIC AREA [ ] [Description] Basic file storage area size [Values to be printed] 0KB to 3072KB PC SAVE AREA [ ] [Description] PC command storage area size [Values to be printed] 0KB to 3072KB OTF SAVE AREA [ ]...
  • Page 60 EVEN: Even ODD: CONTROL [ ] [Description] Transmission control method [Values to be printed] XON+READY AUTO: XON/XOFF+ READY/BUSY(DTR) mode (XON output when the power is on, XOFF output when the power is off) XON/XOFF AUTO: XON/XOFF mode (XON output when the power is on, XOFF output when the power is off) READY/BUSY RTS: RTS mode (No XON output when the power is on, no XOFF output when the power is off)
  • Page 61 [Values to be printed] xxx.xxx.xxx.xxx v6 L [ ] [Description] IPv6 Link local address [Values to be printed] xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx v6 G [ ] [Description] IPv6 Global address [Values to be printed] * From the power-off state, the self-diagnostic print in the system mode is “::”. However, self-diagnosis information can be obtained with BCP SettingTool after starting in online mode.
  • Page 62 [Description] Wireless LAN BAND Setting [Values to be printed] DUAL BAND : 2.4GHz/5GHz using 2.4GHz: 2.4GHz Using 5GHz: 5GHz using CONNECTION MODE [ ] [Description] Wireless LAN: Connection setting [Values to be printed] AP MODE INFRASTRUCTURE ESS ID [ ] [Description] Wireless LAN: ESS ID [Values to be printed] Max.
  • Page 63 [Description] Country Code Setting [Values to be printed] Note: This parameter is set by using the Printer Setting Tool. INIT，USA，CAN，MEX，BRA，CHL，JPN，AUS，NZL，ZAF，CHN， HKG，TWN，KOR，BEL，NLD，LUX，FRA，ITA，DEU，DNK， IRL，GBR，GRC，ESP，PRT，AUT，FIN，SWE，CZE，EST， CYP，LAT，LTU，HUN，MLT，POL，SVN，SVK，BGR，ROM， NOT，LIE，ISL，CHE，IDN，ARG，ARE，MYS，PHL，VNM， COL，THA，TUR，SGP，RUS，IND AP MODE CHANNEL [ ] [Description] Channel setting of AP Mode [Values to be printed] Note: This parameter is set by using the Printer Setting Tool.
  • Page 64 SCAN INTERVAL [ ] [Description] inquiry time setting. [Values to be printed] 18sec～4096sec SCAN WINDOW [ ] [Description] Bluetooth Page scan window setting [Values to be printed] 18sec～4096sec AUTO CONNECT [ ] [Description] Bluetooth Auto re connection setting [Values to be printed] ：Disable Auto Re connection ：Enable Auto Re connection SSP AUTH [1] [2]...
  • Page 65 RETRY POSITION [ ] [Description] Feed amount to retry data write [Values to be printed] -99MM to +99MM RETRY LABELS [ ] [Description] The number of RFID labels to be issued for retry [Values to be printed] 0 to 255 labels READ RETRY [ ] [Description 1] The number of times tag read is retried [Values to be printed 1]...
  • Page 66 TAG CHECK [1] [2] [3] [Description 1] Error tag detection [Values to be printed 1] OFF: Error tag detection is not performed. EPCCODE: Error tag detection is performed. ID area data is read before data write to check for error. PASSWORD: Error tag detection is performed.
  • Page 67 [Description] Time update timing [Values to be printed] start of JOB: Every batch every PAGE: Every page 8.4.1.2 Maintenance Counter/Parameter Settings Display Contents COUNTER [Range] 0.0 ～ 3200.0km TOTAL FEED [Description] Total label distance covered (cannot be cleared) [Range] 0.0 ～ 3200.0km FEED [Description] Label distance covered [Range] 0.0 ～...
  • Page 68 transmissive sensor STORAGE AREA [Description] TrueType Font storage area size [Range] 0KB～3072KB EXT CHR [Description] External character storage area size [Range] 0KB～3072KB BASIC [Description] Basic file storage area size [Range] 0KB～3072KB PC SAVE [Description] PC command storage area size [Range] 0KB～3072KB OTF(SPACE) [Description] OTF save storage area size [Range] 0KB～25600KB...

  • Page 69: Auto Diagnostic

    8.4.2 AUTO DIAGNOSTIC The procedure for printing the self-diagnosis result is the same as that for the maintenance counter/parameter setting data described in 8.4.1 MAINTENANCE COUNTER. The following table shows the menu structure from top menu of the system mode to AUTO DIAGNOSTIC. The menu structure of AUTO DIAGNOSTIC Menu item <1>DIAGNOSTIC...
  • Page 70 AUTO SELF-DIAGNOSIS PRINTOUT PROGRAM BA410T-T PRINTER S/N 2318D120024 MAIN 15NOV2018 V1.0B:F100 BOOT 20APR2018 V1.0 :8E00 XML 22MAY2018 V1.0 :6700 WLAN 05JUL2016 V1.0A:4300 FONT ANKCG :AE00 KANJI :9F00 CHINESE :4D00 FROM 128MB SDRAM 128MB SENSOR1 00000000,00000111 SENSOR2 [H]23ﾟC [A]22ﾟC [R]4.2V [T]2.5V PE LV.
  • Page 71 MAIN 15NOV2018 V1.0B:F100 Checksum Version Creation date (day, month, year) Main Program BOOT 20APR2018 V1.0 :8E00 Checksum Version Creation date (day, month, year) Boot Program XML 22MAY2018 V1.0 :6700 Checksum Version Creation date (day, month, year) XML Program WLAN 05JUL2016 V1.0A :4300 Checksum Version Creation data (day, month, year)
  • Page 72 SENSOR1 0 0 0 0 0 0 0 0 , 0 0 0 0 0 1 1 1 | | | | | | | | Thermal head open sensor | | | | | | | 1: Head closed | | | | | | | (* Do not print when head is open) | | | | | | |...
  • Page 73 HEAD [RANK]1 300DPI Installed head resolution (203DPI / 300DPI) Thermal head resistance rank (0 / 1) LAN MAC 11-22-33-44-55-66 Wired LAN: MAC address EXP.I/O NG OK: Data normal NG: Data error or loopback jig not installed Expansion I/O EX.232C NG OK: Data normal NG: Data error or loopback jig not installed Internal serial interface...
  • Page 74 OK: Normal NG: Abnormal MFi chip (CP chip) iAP Serial 2318T120023 Module-registered iAP Serial iAP Serial Number RFID OK Z#00A:A0 0 (EU0) R00 Module revision (U4 series) Module specification country setting Chip revision Module F/W version Module check result OK: Normal NG: Abnormal RFID module WLAN...
  • Page 75 BASIC M NONE NONE: No program Version: With program BASIC Main Program BASIC S NONE NONE: No program Version: With program BASIC System Program...

  • Page 76: Head Check

    8.4.3 HEAD CHECK The print head check procedure is the same as that for the maintenance counter data described in 8.4.1 MAINTENANCE COUNTER. The following table shows the menu structure from the top menu of the system mode to HEAD CHECK. The menu structure of HEAD CHECK Menu item <1>DIAGNOSTIC...

  • Page 77: Set Parameters

    8.5 SET PARAMETERS Contents of the SET PARAMETERS menu Menu item <2>SET PARAMETERS MEDIA LOAD FEED KEY MOVE TO TEAROFF FW/BK ACT. PRE PEEL OFF BACK FEED SPEED AUTO HEAD CHECK RIBBON NEAR END PAPER/RBN END CALIBRATE POWER SAVE TIME CODE PAGE ZERO FONT CTRL CODE...

  • Page 78: Media Load

    3. In the case the printer cannot detect a gap/black mark while feeding the media, an error occurs on the following condition. Regarding an error during a feed, refer to the External Equipment Interface Specification for the BA400 series When the relation between the stored media pitch (A) and the media pitch...

  • Page 79: Move To Tearoff

    8.5.3 MOVE TO TEAROFF Disables the auto feed to the cut/strip position after printing. Enables the auto feed to the cut/strip position after printing. * Thermal transfer with 2 ips with automatic forward standby ON operates at 3 ips. 8.5.3.1 MOVE TO TEAROFF POS. When the "MOVE TO TEAROFF”...
  • Page 80 8.5.5.1. PRE PEEL OFF POS Fine adjustment position setting when “Yes / ON (with pre-peeling operation)” is specified in “Pre-peeling treatment / PRE PEEL OFF”. Max. Integer Decimal Unit of Min. value Step Display Sign 0-padding value digit place measure +9.9 -2.5 Decimal...

  • Page 81: Back Feed Speed

     If the distance sent forward from the peeling table is not appropriate, such as when the gap between labels is large, finely adjust the pre-peeling.  When the fine adjustment setting is entered, a test operation for confirming an appropriate fine adjustment value can be executed.
  • Page 82 * Printing of the half-finished label is completed.  LCD message “NO PAPER”  The remaining number of labels [Specified number of labels]  [The number of finished labels at the time of printing stop (including the half-finished label)] If a label end is detected while the last one of the specified number of labels is printed, the remaining number of labels on the LCD will be blank.

  • Page 83: Calibrate

    Initial feed … Restart label … Finished (*) Printing: 4 label … Finished (*) Printing: 5 (*) Completely printed labels: 1 and 5 labels (3) Ribbon end detection: In the case unfinished label length is less than 30 mm  Printer behavior When a label end is detected in the middle of printing, the printer completes the half-finished printing and stops when the next label is at the home position, displaying the error message.
  • Page 84 Notes: 1. When this parameter is enabled, an automatic calibration starts at an open/close of the print head and when power is on. 2. When this parameter is enabled, the media length, effective print length, sensor type and whether the ribbon is used or not, will be specified with commands, as handled as follows.

  • Page 85: Power Save Time

    8.5.11 POWER SAVE TIME Max. Integer Decimal Unit of Min. value Step Display Sign 0-padding value digit place measure Decimal None None Min. 8.5.12 CODE PAGE PC-850 PC-852 PC-857 PC-8 PC-851 PC-855 PC-1250 PC-1251 PC-1252 PC-1253 PC-1254 PC-1257 LATIN9 Arabic PC-866 UTF-8 8.5.13...

  • Page 86: Peel Off Status

    Note: The mode specified by the command may be different from the actual mode, depending on the status of this parameter. Also, the data transmission method differs partly. For details, refer to the BA400 Series External Equipment Interface Specification. 8.5.19...

  • Page 87: Multi Label

    8.5.20 MULTI LABEL ・OFF: Disable Multi Label function ・ON: Enable Multi Label function Note: This function is not available when printer prints without sensor This function is not available when printer prints with Calibration ON. Number of Multi labels are 8 labels. Example Label pitch 30mm and Gap length 2mm, printer will regard 3labels as 1label.

  • Page 88: Feed Adj

    8.5.23 FEED ADJ. Max. Integer Decimal Unit of Min. value Step Display Sign 0-padding value digit place measure +50.0 -50.0 Decimal Exist None +0.0 mm Print start One label position +3.0 mm Print start One label position -3.0 mm Paper feed direction One label Print start position Note: The feed amount fine adjustment value is the sum of the fine adjustment values set in the system...

  • Page 89: Cut Adj

    8.5.24 CUT ADJ Max. Integer Decimal Unit of Min. value Step Display Sign 0-padding value digit place measure +50.0 -50.0 Decimal Exist None +0.0 mm Cut position +3.0 mm Cut position -3.0 mm Cut position Paper feed direction Notes: 1. The cut position fine adjustment value is the sum of the fine adjustment values set in the system mode (by key operation) and set by command (from the PC).
  • Page 90 The cut position fine adjustment value can be calculated using the following method. If a calculated value does not work to feed the media backward to the proper home position, the cut position needs to be re-adjusted with another value. Note: When this procedure is used, one or more printed labels are left between the print head and the cutter.
  • Page 91 3. Strip position fine adjustment 0.0mm +3.0mm -3.0mm Printing in strip issue mode is stopped at the position where the distance from the middle point of the gap between labels to the end of the strip shaft is 4 mm, since the gap between labels is assumed to be 2 mm.

  • Page 92: Back Adj

    8.5.25 BACK ADJ. Max. Integer Decimal Unit of Min. value Step Display Sign 0-padding value digit place measure +9.9 -9.9 Decimal Exist None +0.0mm Print start position (Home position after a back feed) +3.0mm Print start position (Home position after a back feed) -3.0mm Print start position (Home position after a back feed)

  • Page 93: Adjust

    8.5.26 X ADJUST Max. Integer Decimal Unit of Min. value Step Display Sign 0-padding value digit place measure +99.9 -99.9 Decimal Exist None Notes: 1. The X ADJUST parameter can fine adjust the print position in X-coordinate (horizontal direction). The fine adjustment shall be performed so that the print position falls within the effective print width.

  • Page 94: Tone Adj.

    8.5.28.1. TRANS. (RIBBON) NORM: Normal HIGH : High LOW: Low SA1: SA Type1 SA2: SA Type2 Rev3: Reserve3 Rev4: Reserve4 Rev5: Reserve5 Rev6: Reserve6 Rev7: Reserve7 (Supplement) When SA Type2 is selected, the operation is the same as High. 8.5.28.2. DIRECT NORM: Normal HIGH: High LOW: Low...

  • Page 95: Tone Adj.

    8.5.30 TONE ADJ. <D> Max. Integer Decimal Unit of Min. value Step Display Sign 0-padding value digit place measure Decimal Exist None Step Remarks: 1. Setting a value in the positive (+) direction, the print tone becomes darker. And, setting a value in the negative (-) direction, the print tone becomes lighter.

  • Page 96: Rear Ribbon Motor

    8.5.33 REAR RIBBON MOTOR The menu structure of REAR RIBBON MOTOR menu Menu item <2>SET PARAMETERS REAR RIBBON MOTOR Normal Torque Low Torque 8.5.33.1. Normal Torque Max. Integer Decimal Unit of Min. value Step Display Sign 0-padding value digit place measure Decimal Exist...

  • Page 97: Test Print

    8.6 TEST PRINT Contents of TEST PRINT menu Menu item <3>TEST PRINT PRINT CONDITION SLANT LINE(1DOT) SLANT LINE(3DOT) CHARACTERS BARCODE NON-PRINTING FACTORY TEST AUTO PRINT(TRANS.) AUTO PRINT(REFL.) 8.6.1 PRINT CONDITION The menu structure of PRINT CONDITION Menu item <3>TEST PRINT PRINT CONDITION ISSUE COUNT PRINT SPEED...
  • Page 98 8.6.1.1. ISSUE COUNT 1000 5000 8.6.1.2. PRINT SPEED Selectable printer speed differs depending on the resolution. Resolution 203dpi 300dpi Print speed 2 ips Supported Supported 4 ips Supported Supported 6 ips Supported Supported 8 ips Supported Supported When select 2"/sec on thermal transfer mode , it will print at 3"/sec. 8.6.1.3.

  • Page 99: Slant Line (1Dot)

    8.6.1.6. LABEL PITCH Max. Integer Decimal Unit of Min. value Step Display Sign 0-padding value digit place measure Decimal None None 8.6.1.7. PAPER FEED NO FEED FEED 8.6.2 SLANT LINE (1DOT) 1-dot slant lines Magnification of slant lines 1-dot slant lines (Black area ratio: 16.7%)

  • Page 100: Slant Line (3Dot)

    8.6.3 SLANT LINE (3DOT) 3-dot slant lines Magnification of slant lines 3-dot slant lines (Black area ratio: 16.7%)

  • Page 101: Characters

    8.6.4 CHARACTERS Gothic + Mincho Gothic + Chinese...

  • Page 102: Barcode

    8.6.5 BARCODE 8.6.6 NON-PRINTING The printer feeds blank label. 8.6.7 FACTORY TEST...

  • Page 103: Auto Print (Trans.)

    8.6.8 AUTO PRINT (TRANS.) The factory test print is performed on the following conditions, therefore, the parameter settings and the print density fine adjustment value are ignored. Key functions after printing of each test pattern are as follows. [PAUSE] key (or its substitute key): Next printing is performed.

  • Page 104: Sensor

    8.7 SENSOR Contents of SENSOR menu Menu item <4>SENSOR TEMPERATURE ADJUSTMENT THRESHOLD LEVEL 8.7.1 TEMPERATURE The ambient temperature and print head temperature are displayed. Only when the temperature is below zero, the symbol of minus (-) is displayed. The display is updated every 200 msec. The range of each temperature is shown below.
  • Page 105 8.7.2.2 TRANSMISSIVE SENSOR The sensor level of the transmissive sensor is registered. Remove some labels and place the backing paper so that the Transmissive sensor can detect it. The display of the currently detected value is updated every 200 msec. Hold down the [FEED] key for 3 seconds or more.

  • Page 106: Threshold Level

    8.7.3 THRESHOLD LEVEL The menu structure of THRESHOLD LEVEL menu Menu item <4> SENSOR THRESHOLD LEVEL REFLECT THRESHOLD1 THRESHOLD2 THRESHOLD3 THRESHOLD4 THRESHOLD5 TRANS. THRESHOLD1 THRESHOLD2 THRESHOLD3 THRESHOLD4 THRESHOLD5 8.7.3.1 REFLECT Max. Integer Decimal Unit of Min. value Step Display Sign 0-padding value digit...

  • Page 107: Ram Clear

    8.8 RAM CLEAR Contents of RAM CLEAR menu Menu item <8>RAM CLEAR NO RAM CLEAR MAINTE.CNT CLEAR PARAMETER CLEAR 8.8.1 NO RAM CLEAR This option is provided for users who access this menu by mistake, and intended to exit from the RAM clear menu without performing any RAM clear.

  • Page 108: Parameter Clear

    2. LCD message while a maintenance counter clear is performed Display ALL COUNTER CLEAR... While clearing ALL COUNTER After the maintenance counter COMPLETED clear is completed Turn off the printer 3. After the maintenance counter clear is completed, turn off the printer when “COMPLETED. Turn off the printer”...
  • Page 109 3. Parameter settings to be cleared and the initial values set after parameter clear  Settings printed on the maintenance counter/parameter setting data printout <<ADJUST>> Item Description Initial value [PC] / [KEY] Feed amount fine adjustment value [PC] +0.0mm [KEY] +0.0mm FEED Cut position/Strip position fine adjustment [PC] +0.0mm [KEY] +0.0mm...
  • Page 110 BACK FEED SPEED Reverse feed speed (Note) CALIBRATION Auto calibration CODE PAGE Character code selection PC-850 Character “0” selection 0 (without slash) CTRL CODE Control code type AUTO PEEL OFF STATUS Whether to send a peel-off wait status to the host USB I/F STATUS Whether to return a response to the host via USB...
  • Page 111 << PANEL >> Item Description Initial value LANGUAGE LCD message language QM TYPE ENGLISH JA TYPE JAPANESE CN TYPE Simplified CHINESE MODEL NAME Whether to display the model name PRINTED COUNTER Whether to display the number of labels printed IP ADDRESS Whether to display the IP address CONTRAST Contrast of the LCD...
  • Page 112 Item Description Initial value BLUETOOTH Bluetooth Setting Settings to distinguish device nicknames FACTORY TEST DEVICE NICKNAME Bluetooth Device Nickname TOSHIBA TEC BT BD ADDRESS Bluetooth Device address Not cleared. * Module specific INQUIRY Inquiry setting EVERY SCAN INTERVAL Scan Interval setting...
  • Page 113 SCAN WINDOW Scan Window setting SECURITY Security Level setting AUTO CONNECT Auto Re-connection setting SSP AUTH SSP Authentication JUST WORKS NUMERIC CONP Numeric comparison setting NO IN/OUT << RFID >> Item Description Initial value MODULE TYPE RFID module type NONE TAG TYPE RFID tag type NONE...

  • Page 114: Initial Setting

    （RAM Clear QM Type） 1．After Parameter Clear QM TYPE CLEAR... ↓ QM TYPE COMPLETED Turn off the printer ↓ Turn OFF/ON BA400 Series Initializing... ↓ 2 ． Show Initial Setting STARTUP SETTINGS wizard PRESS [PAUSE] ↓ [PAUSE] 3．Language Setting Selected by [FEED]、[RESTART]...
  • Page 115 ↓[PAUSE] 4．Print Mode Setting Selected by [FEED]、[RESTART] PRINT MODE w/RIBBON ▲ With RIBBON Without RIBBON ▼ [F]/[R]Select [P]Set ↓[PAUSE] 5．Calibrate Setting Selected by [FEED]、[RESTART] CALIBRATE ▲ LABEL/GAP BLACK MARK ▼ [F]/[R]Select [P]Set 6．-1 Calibrate setting select except “OFF “ 6．-1-1 INITIAL CONFIGURATION Finish setting FINISH？...
  • Page 116 8．DHCP Client DHCP CLIENT INIT... Initializing ↓ 9．ONLINE mode BA410T-G V1.0A ONLINE PRINTED 000000 IP:192.168.010.020 Key operation (Wizard screen) Function [FEED] + [RESTART] Display the upper screen without saving the settings. [PAUSE] In the case of the setting selection screen, the setting is saved and the next screen is displayed.

  • Page 117: Interface

    8.9 INTERFACE Contents of INTERFACE menu Menu item <6>INTERFACE LAN/WLAN RS-232C CENTRONICS EXP.I/O BLUETOOTH KB I/F 8.9.1 LAN/WLAN The menu structure of LAN/WLAN Menu item <6>INTERFACE LAN/WLAN LAN/WLAN BASIC INFORMATION IP ADDRESS SUBNET MASK GATEWAY ADDRESS DHCP DHCP CLIENT ID DHCP HOST NAME SOCKET PORT PORT NUMBER...
  • Page 118 8.9.1.3 IP ADDRESS IP address is displayed and set. 8.9.1.4 SUBNET MASK Subnet mask is displayed and set. 8.9.1.5 GATEWAY ADDRESS Gateway address is displayed and set. 8.9.1.6 DHCP Select whether to enable DHCP. 8.9.1.7 DHCP CLIENT ID Enter a DHCP client ID with Hex. code. Setting range: 00 to 63 (64 bytes) 8.9.1.8 DHCP HOST NAME Enter a DHCP host name with ASCII code.
  • Page 119 8.9.1.14 WLAN The menu structure of WLAN Menu item <6>INTERFACE LAN/WLAN WLAN BAND SELECT CONNECTION MODE ESSID 8.9.1.14.1 BAND SELECT DUAL BAND 2.4GHz 5GHz 8.9.1.14.2 CONNECTION MODE AP MODE INFRASTRUCTURE 8.9.1.14.3 ESSID Enter an ESSID with ASCII code. Setting range: 00 to 31 (32 bytes)

  • Page 120: Usb

    8.9.2 The menu structure of USB Menu item <6>INTERFACE USB SERIAL ID USB I/F STATUS 8.9.2.1 USB SERIAL ID 8.9.2.2 USB I/F STATUS OFF: No response is returned. Returns a response to the host via USB. Notes: 1. Regardless of the setting of this parameter, the status indicating the end of issue is automatically returned.

  • Page 121: Rs-232C

    8.9.3 RS-232C The menu structure of RS-232C Menu item <6>INTERFACE RS-232C BAUD RATE DATA LENGTH STOP BIT PARITY CONTROL 8.9.3.1 BAUD RATE 2400 bps 4800 bps 9600 bps 19200 bps 38400 bps 115200 bps 8.9.3.2 DATA LENGTH 8 bits 7 bits 8.9.3.3 STOP BIT 1 bit 2 bits...

  • Page 122: Centronics

    8.9.4 CENTRONICS The menu structure of CENTRO. Menu item <6>INTERFACE CENTRONICS ACK/BUSY INPUT PRIME PLUG & PLAY 8.9.4.1 ACK/BUSY Rising edge Trailing edge 8.9.4.2 INPUT PRIME 8.9.4.3 PLUG & PLAY Note: This setting operates as disabled/OFF even when enabled/ON. 8.9.5 EXP.I/O TTEC Standard Inline...

  • Page 123: Kb I/F

    8.9.6.2 FACTORY TEST 8.9.6.3 INQUIRY EVERY 60sec 8.9.6.4 SECURITY LINK 8.9.6.5 SCAN INTERVAL Setting Range：18～4096（sec） 8.9.6.6 SCAN WINDOW Setting Range：18～4096（sec） 8.9.6.7 AUTO CONNECT 8.9.6.8 SSP AUTH JUST WORKS NUMERIC COMP ――――――― NO IN/OUT DISP ONLY DISP Y/N 8.9.7 KB I/F KB-70...

  • Page 124: Rfid

    8.10 RFID Contents of RFID menu Menu item <7>RFID TEST MODULE RETRY UHF SETTING OTHER CARRIER SENSE 8.10.1 TEST RFID tag data related to the test is read. Menu item <7>RFID TEST ID READ 8.10.1.1 ID READ The printer enters the read test mode, and a read test is performed each time the [PAUSE] key is pressed. When the data of a tag can be read, it is displayed on the LCD.

  • Page 125: Module

    The number of tag being read/The total number of tags read (Mostly, only 1 tag is read.) For the UHF module, AGC value of the read tag is displayed with decimal number. Data displayed on the 3rd and 4th lines are expressed with hex. code. (16 digits x 2 lines = 32 digits) The EPC code for the EPC area is displayed.
  • Page 126 The following message is displayed depending on the module type setting, the mounted module type, and the module mount condition. Module Type Module type and status Message parameter NONE No module installed. NONE No module installed. No RFID Module BA704-RFID-U4-S Country of use [PAUSE] for Setting BA704-RFID-U4-KR-S...

  • Page 127: Retry

    8.10.2.4 RF CHANNEL A channel used for RFID tag write is set. AUTO Notes: 1. When a channel is chosen from 2CH to 8CH, that channel will be continuously used. 2. When the channel is set to AUTO, an available channel is searched in the following order: (2CH ...
  • Page 128 8.10.3.3 READ RETRY The number of times tag read is retried and the timeout for read retry are set. (1) The number of times tag read is retried Max. Integer Decimal Unit of Min. value Step Display Sign 0-padding value digit place measure...

  • Page 129: Uhf Setting

    8.10.4 UHF SETTING The parameters related to UHF setting are set. The menu structure of UHF SETTING Menu item <7>RFID UHF SETTING POWER LEVEL Q VALUE AGC THRESHOLD WRITE AGC THRESHOLD WRITE RETRY MIN AGC CALIB. MODE ENCODE. POSITION 8.10.4.1 POWER LEVEL Radio output level of UHF is set.
  • Page 130 8.10.4.3 AGC THRESHOLD Max. Integer Decimal Unit of Min. value Step Display Sign 0-padding value digit place measure Decimal None None None When the obtained gain of an RFID tag is lower than the AGC threshold, the tag is considered as an error tag even if a data write succeeds.
  • Page 131 8.10.4.5 WRITE RETRY MIN AGC Max. Integer Decimal Unit of Min. value Step Display Sign 0-padding value digit place measure Decimal None None None When the Q value is set to 1 or above, the AGC threshold lower limit for retry becomes effective. In the case the printer could not find any tag whose gain is over the AGC threshold for data write, the AGC threshold is lowered to the highest gain of the detected tags whose gains are over the AGC threshold lower limit for retry specified with this parameter.
  • Page 132 8.10.4.7 ENCODE POSITION By performing an RFID calibration, an optimum data read/write position (distance from the home position) is automatically obtained and set. Max. Integer Decimal Unit of Min. value Step Display Sign 0-padding value digit place measure +999.9 -999.9 Decimal None None...

  • Page 133: Other

    8.10.5 OTHER The menu structure of OTHER Menu item <7>RFID OTHER TAG CHECK MULTI WORD WRITE TAG CHECK OFF: Error tag detection is not performed. ON (ID): Error tag detection is performed. ON (ACCESS PASSWORD): Error tag detection is performed. Notes: 1.
  • Page 134 (When “ON” is selected) ↓ [PAUSE] key 5. Tag check setting Enter a 4-digit protection password. protection password setting screen ↓ [PAUSE] key This menu is ended, and the upper-level screen is displayed. 4. Example of operation when the tag check setting protection password has been set (when “ON” is set on the tag check setting protection password setting screen) Display Operation...

  • Page 135: Carrier Sense

    8.10.6 CARRIER SENSE The printer enters the carrier sense mode, and performs a carrier sense. Environmental radio wave of each channel is picked up for about 30 times during 5 seconds. The menu structure of CARRIER SENSE Menu item <7>RFID CARRIER SENSE Display example Display...

  • Page 136: Rtc

    8.11 RTC Contents of RTC menu Menu item <8>RTC DATA/TIME BATTERY CHECK RENEWAL 8.11.1 DATE TIME This setting is effective only when the optional RTC module is installed. Date and time are set. 8.11.2 BATTERY CHECK 8.11.3 RENEWAL Start of JOB As the real time clock data is read only for the first media in a batch, the same time is printed on the all media.

  • Page 137: Factory Test

    8.12 FACTORY TEST Contents of FACTORY TEST menu Menu item <10>FACTORY TEST PANEL TEST KEY TEST 8.12.1 PANEL TEST The LCD test is performed in the following order. (Start)  Backlight test  Missing dot test  Character display test  Contrast test  (End) The display language is English regardless of the LCD Language parameter setting.
  • Page 138 ONLINE LED turns on. ERROR LED turns on. Backlight turns on. 1-dot check pattern is displayed. The upper left corner dot is white. Press any key. Character display test ONLINE LED turns on. ERROR LED turns on. Backlight turns on. Character display Press any key.

  • Page 139: Key Test

    8.12.2 KEY TEST The test is performed in the following order. (Start)  FEED key test  RESTART key test  PAUSE key test  (End) The display language is English regardless of the LCD Language parameter setting. Operation and LCD/LED status FEED KEY TEST Press the [FEED] key.

  • Page 140: Basic

    8.13 BASIC Contents of BASIC menu Menu item <11>BASIC BASIC FILE MAINTENANCE TRACE SYSTEM PROGRAM 8.13.1 BASIC 8.13.2 FILE MAINTENANCE The block numbers and BASIC program file names (up to 12 characters) stored in the BASIC program storage area are displayed. If the file name exceeds 12 characters, the overflowing characters are not displayed.

  • Page 141: Lcd Panel

    8.15 LCD PANEL Contents of LCD PANEL menu Menu item <13>LCD PANEL LANGUAGE DISPLAY CONTRAST 8.15.1 LCD LANGUAGE ENGLISH GERMAN FRENCH DUTCH SPANISH JAPANESE ITALIAN PORTUGUESE Simplified CHINESE KOREAN TURKISH POLISH Note: In the printer modes other than online, the language displayed on the LCD panel is JAPANESE when JAPANESE is selected, and ENGLISH when ENGLISH, GERMAN, FRENCH, DUTCH, SPANISH, ITALIAN, PORTUGUESE, Simplified CHINESE, KOREAN, TURKISH, or POLISH is selected.

  • Page 142: Contrast

    8.15.2.3 IP ADDRESS IP address is hidden. IP address is displayed. 8.15.3 CONTRAST Max. Integer Decimal Unit of Min. value Step Display Sign 0-padding value digit place measure Decimal None Enabled None Note: Contrast setting + (Plus) Higher contrast - (Minus) Lower contrast 8.16 PASSWORD Contents of PASSWORD menu...
  • Page 143 Password entry for user system mode Display Procedure Turn on the printer, press the [PAUSE] key to place the printer in pause state. Then, hold down the [RESTART] key for 3 seconds. The password entry screen is displayed. Enter the password. The printer enters the user system mode.

  • Page 144: User System Mode

    9 USER SYSTEM MODE OUTLINE OF USER SYSTEM MODE 1. The printer enters the user system mode with the following operations.  While the printer is in pause state, perform either of the following operations: Hold down the [RESTART] key for 3 sec. or more. 2.

  • Page 145: Set Parameters

    9.3 SET PARAMETERS Same as 8.5 SET PARAMETERS of the system mode. 9.4 DETECTION LEVEL Contents of DETECTION LEVEL menu Menu item <3>DETECTION LEVEL 1)REFL.(PRE-PRINT) 2)TRANS.(PRE-PRINT) Same as 6.6 MANUAL THRESHOLD SETTING. SYSTEM TOOLS Menu item <4>SYSTEM TOOLS DUMP USB MEMORY PRINT ON DEMAND ...

  • Page 146: Dump

    9.6 DUMP A dump list of the received data of each interface can be printed or saved to a USB memory. However, when an RFID write error occurs, the dump list printing function cannot be used. USB MEMORY : Save to USB memory PRINT : Print on label ON DEMAND...

  • Page 147: Issue Control

    ISSUE CONTROL Menu item <5> ISSUE CONTROL Sensor Mode Print speed Ribbon Direction Auto status Sensor COMMAND REFLECTIVE TR.Threshold1 TR.Threshold2 TR.Threshold3 TR.Threshold4 TR.Threshold5 RE.Threshold1 RE.Threshold2 RE.Threshold3 RE.Threshold4 RE.Threshold5 * This setting is disabled when the auto calibration setting is enabled. Mode COMMAND BATCH...

  • Page 148: Show Issue Condition

    [Explanation] The issue control setting affects only TPCL mode. SHOW ISSUE CONDITION Contents of SHOW ISSUE CONDITION menu Menu item <6>SHOW ISSUE CONDITION Sensor (*1) Mode (*1) Print speed (*1) Ribbon (*1) Direction (*1) Media pitch (*1) Print length (*1) Print width (*1) Media width...

  • Page 149: Reset

    Ribbon NO (Direct) Direction BOTTOM BOTM/Mir TOP/Mir Media pitch (10.0 - 1500.0) mm Print length (6.0 - 1498.0) mm Print width BA410/420T-G(203dpi) (10.0 - 104.0) mm BA410/420T-T(300dpi) (10.0 – 105.7) mm Media width (30.0 - 112.0) mm [Explanation] The display item of the issue control confirmation is reflected only when the issue condition of TPCL is changed.

  • Page 150: Download

    10 DOWNLOAD Power OFF (1) Power off state (2) Turn the power on while holding down the [FEED], [RESTART] and [PAUSE] keys at the same time. (3) Download mode display Start of download (4) Send a download command. (5) The printer starts receiving the data. (6) The printer is receiving the data (7) Data is being checked.
  • Page 151 When error occurs while downloading data with download mode, the following error message will be displayed: Error message Error message Description Communication error (Command error) The checksum of the boot program does not end with “00”. Downloading the boot program for wrong PCB was attempted.
  • Page 152 Download Bluetooth module firmware POWER OFF (1) Power off state (2) Turn the power on while holding down the [FEED], [RESTART] and [PAUSE] keys at the same time. DOWNLOAD MODE Waiting for data... □□□□□ (3) Printer FW download mode display. [FEED]+[PAUSE] (4) Hold down the [FEED] and [PAUSE] key at the same time.

  • Page 153: Auto Configuration Mode

    11 Auto Configuration Mode 11.1 Outline of the Auto Configuration Mode When turning on the printer while holding down the [FEED] key, the printer to start auto configuration mode. The auto configuration mode allows for automatically downloading the master firmware and restarting the printer.

  • Page 154: Auto Configuration File

    11.3 Auto Configuration File To execute the auto configuration mode, it is required to create the auto configuration file, which is an exclusive CFG file, in the USB memory in advance. The auto configuration file is stored in the following path under the name of “AUTO CONFIG.CFG”. /ATA0/SYSTEM/AUTOCONFIG.CFG 11.3.1 Format...

  • Page 155: Power Save Function

    12 Power Save Function 1. Printer status allowing shift to the power save mode When the following status continues for a specified length of time, the printer will enter the power save mode and show the power save mode message. (Refer to 5. Power save mode display described below.) However, if KB-70 is connected and the following state continues for more than the set power saving time, the printer will be turned off.
  • Page 156 5. Message in the power save mode The language differs depending on the printer status before the printer enters the power save mode. Printer status before power save Supported language Online mode (except for manual Multi-language threshold setting) System mode, User system mode Japanese/English and manual threshold setting in online mode...

This manual is also suitable for:

Ba410Ba420

Table of Contents
