Specifications - TASKING iSYSTEM AURIX DAP User Manual

Specifications

GENERAL
Operating temperature 10°C to 40°C
Storage temperature
MECHANICAL
Size
Weight
ELECTRICAL
Isolation Type
Isolation Ratings
VIORM *
DEBUG TOOL SIDE
Supply Voltage
Max Supply Current
TARGET SIDE
Supply Voltage
Max Supply Current
PERFORMANCE
DAP
VIORM is defined as the maximum repetitive peak voltage that the isolator can withstand.
Make sure that the target side provides a reference voltage (VREF) for the adapter to work
properly.
-10°C to 60°C
65 x 40 x 19 mm
approx. 55 g
Basic
1 kVrms
560 V peak
5 V (via attached power supply)
50 mA
3 V - 5 V (via VREF)
50 mA
Up to 2 MHz
