Specifications - TASKING iSYSTEM CoreSight Hardware User Manual

Specifications

GENERAL
Operating temperature 10°C to 40°C
Storage temperature
MECHANICAL
Size
Weight
ELECTRICAL
Isolation Type
Isolation Ratings
VIORM *
DEBUG TOOL SIDE
Supply Voltage
Max Supply Current
TARGET SIDE
Supply Voltage
Max Supply Current
PERFORMANCE
JTAG
SWD
VIORM is defined as the maximum repetitive peak voltage that the isolator can with-
stand.
Make sure that the target side provides a reference voltage (VREF) for the adapter to
work properly.
-10°C to 60°C
65 x 40 x 19 mm
approx. 55 g
Basic
1 kVrms
560 V peak
5 V (via attached power supply)
50 mA
3 V - 5 V (via VREF)
50mA
Up to 50 MHz
Up to 2 MHz
