Before You Start

• Keep the following ready:

• Power supply.

• A SIP Account from an ITSP to test VoIP connectivity.

• A standalone computer or a computer connected in a LAN to access Jeeves, the web-

based configuration tool of SETU VFX.

• Appropriate cables and connectors to set up and test the WAN interface of SETU VFX and

the LAN connection.

• An Analog Trunk Line from the CO/PSTN to connect to the FXO Port, if applicable.

• At least one standard telephone instrument to connect to the FXS Port, if applicable. You

can also connect a fax machine or a PBX.

• Necessary telecom wiring for the lines and devices to be connected to the FXS and FXO

Ports.

• Standard, good quality, twisted pair telephone cables with 0.5mm conductor diameter

and RJ11 plugs for the FXS and FXO Ports.

•

Do not install this product near any area where,

•

it is exposed to direct sunlight, heat, excessive cold or humidity, dust, oil, corrosive fumes.

•

there is a water source (wash basin, tub, shower, pool, sprinkler, etc.)

•

there is source of electromagnetic noise such as radio equipment, heavy transformers,

faulty electric chokes of tube-lights, device having a faulty coil.

•

Ensure proper electrical earth and telecom earth for the safety of the product and persons

handling it.

•

Always wear an electro static discharge preventive wrist wrap or belt and use a grounding mat

when handling the product and its parts.

•

SETU VFX contains a 3VDC/18mAh (Li-Al) alloy-Manganese Dioxide Coin Battery (ML 1220 -

Rechargeable) of diameter 12.5mm and height 2.0mm. Battery should be replaced only by

authorized dealers of Matrix. There is a risk of explosion if the Battery is replaced in an incorrect

manner. Please dispose-off used Batteries.

Getting Started

• Select an appropriate site to install the SETU VFX, considering the safety precautions listed

earlier in this chapter.

• Unpack SETU VFX and verify the package contents:
