3. DEVICE DESCRIPTION

3.1 Use

This charging station is especially designed for public areas.
The station can be installed in various environments: in paved areas, in open soil/sand, or in asphalt
surfaces.
The following environments, however, are not suitable:
- All grounds that can flood
- Loading quays
- Slope at an angle of more than 4%

3.2 Accessories

The following accessories will not be provided: tools, foundation.
3.3 Safety provisions
- 2 half euro profile cylinders
- Extra caps behind front cap
- 12 Volt control voltage
- Components comply with IP2 at least
- Strain reliefs
- 4 mm steel casing
- IP54 (lowest waterproof class for Mennekes outlets).

4. SAFETY

Read the following safety regulations carefully before you install and use the charging station.

4.1 Safety regulations

Before you install the charging station, you must make sure the location is safe for all bystanders. NEVER allow children onto
this worksite. Never allow ANYONE who has nothing to do with the work onto the worksite.
- Never be distracted while you are performing the work.
- Make sure you maintain a healthy posture at all times while doing the work.
- Do not leave any tools or charging station components unattended.
- Make sure any tools you are using are clean and dry.
- Make sure that the charging station, tools and components will stay dry when it is raining.
Make sure that there is no danger of anyone tripping over objects or paving while you are digging the
hole for the foundation.
Make sure to wear good, suitable gloves for any special actions throughout the entire installation and
connection process.
