LEGRAND ecotap Duo Manual page 12

Weight (kg)
Number of charging points
Socket
Cable
Electrical characteristics
Power output per socket
Operating voltage (Ue) / Current rates (In A, In C)
Impulse voltage (Uimp)
Insulation voltage (Ui)
Frequency (fn)
Rated voltage
Voltage tolerance (V) regardless of vehicle requirements
Integrated protection system on charging station
Integrated protection system per charge point
Conditional short-circuit
Allowable thermal stress in Short Circuit
Connection to the mains
Type of load
Vehicle connection Mode 3 connector socket
(60451810 / 60451110 / 60451610 / 60081812 /
60081112 / 60081612 / 60081813 / 60081114 /
60081614)
Vehicle connection Mode 3 attache cable connector
(60111810 / 60321110 / 60161610 / 60321610 / 60102215
/ 60102205 / 60080199 / 60080198)
AC meters
12. www.ecotap.nl
45 kg for 60451810 / 60451110 / 60451610 / 60081812
/ 60081112 / 60081612 / 60081813 / 60081114 /
60081614
49 kg for 60111810 / 60321110 / 60161610 / 60321610 /
60102215 / 60102205 / 60080199 / 60080198
2
Type 2
Type 2
0 to 22 kW for 60321110 / 60321610 / 60451810
/ 60451110 / 60451610 / 60081812 / 60081112 /
60081612 / 60081813 / 60081114 / 60081614 /
60102215 / 60102205
0 to 11 kW for 60111810 / 60161610 / 60080199 /
60080198
Single-phase cabling, phase + N 230V~ from 0 to 32A
(determined at 20°C)
Three-phase cabling, 3 phases + N 400V~ from 0 to 32A
(determined at 20°C)
4kV
230V single-phase
500V three-phase
50Hz/60Hz
1 phase + N: 230V - 3 phases + N: 400V
195V - 265V
Fuse type gG 63A
MCB 40A curve C
RCD 40A 30mA Type B
6000A IEC/EN 60898-1
10kA IEC/EN 60947-2
16 000 A²s
Phase/Neutral, rigid cable, 2.5 to 35 mm², screw terminals
H07 V R/U Earth, rigid cable, 2.5 to 35mm², screw terminals
H07 V R/U
Mode 3 charging terminal equipped with a locking system
for Mode 3
Type 2 3P+N (single-phase compatible) with pilots compliant
with IEC 62191-1 and IEC 62196-2.
Use only a manufacturer-approved plug with silver-plated
contacts.
Use of extension and adapter prohibited. .
Type 2 3P+N (single-phase compatible) with pilots compliant
with IEC 62191-1 and IEC 62196-2.
Use of extension and adapter prohibited.
60080199 / 60080198: 4m curl 3x16A
60111810 / 60161610: 4m straight 3x16A
60321110 / 60321610 / 60102215 / 60102205: 8m
straight 3x32A
MID certified, Class B according to EN 50470-1, -3
