- Page 1 Wallcharger Duo Manual...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Introduction General Warranty Symbols used in this manual and charging system Device description Application Accessories Safety device Safety Safety regulations Mandatory checks before initial use User / installation manual Required power cable Wall mounting Overview of the charging station Maintenance Transportation and storage Malfunction explanation... -
Page 3: Introduction
1. INTRODUCTION Thank you very much for selecting the Ecotap® wall-mounted charging station. This manual describes the Wall Charging Station equipped with two type 2 sockets of 22kW each. This manual contains important information for the proper and safe installation and use of this charging station. The charging station is designed to supply power to vehicles equipped with a modus 3 charging system in accordance with DIN EN 50556, IEC 61851-1 (edition2.0), VDE- AR-N 4102 appendix: 2012-04. -
Page 4: Device Description
Disconnect the electrical installation from its power supply Reading this manual is mandatory 3. DEVICE DESCRIPTION 3.1 Application The Wallcharger DUO has been specially designed for wall-mounting. 3.2 Accessories The following accessories are not included in the scope of delivery: •... -
Page 5: Mandatory Checks Before Initial Use
Always check any measuring instruments you will be using to disconnect the installation from its power supply before you use them, checking them several times to make sure they are working properly. 5. MANDATORY CHECKS BEFORE INITIAL USE The following checks are mandatory before commissioning the recharging column. NEVER use the recharging column if one or more checks show that power supply or stability of the recharging column does not satisfactory. - Page 6 When mounting the charging station, you should take into account the strength of the wall. The wall should be completely closed, without any holes or openings. If these are present, they must first be filled. Use the right fastening screws to firmly secure the charging station to the wall and use all four fastening holes. Mounting material is included.
- Page 7 www.ecotap.nl 13-07-23...
-
Page 8: Overview Of The Charging Station
6.3 Overview of the charging station Antenna Network meter Socket type 2 IEC 61815-1VDE- AR-E2623-2-2 Controller module Transparent plastic cover made of Lexan to be removed only by Ecotap B.V. or by an authorised person 12V transformer Contactor Residual current circuit 3-phase fuse element 32A GG breaker 7. -
Page 9: Transportation And Storage
8. TRANSPORTATION AND STORAGE When transporting the wall charger, avoid damaging the paintwork. This could cause rusting. Store the wall charger preferably in a dry, non-damp room. 9. MALFUNCTION EXPLANATION If the charging station is not functioning properly, please contact the back office provider or contact another certified mechanic with the right measuring and testing equipment with car simulation. - Page 10 Weight (kg) 21kg for 55451800 / 55451100 / 55451600 / 55483702 / 55081800 / 55081100 / 55081600 / 55483703 / 55081602 / 55081102 / 55081801 25kg for 55161800 / 55161100 / 55161600 / 55321800 / 55321100 / 55321600 / 55320014 / 55320013 / 55160012 / 55321604 Number of charging points Socket...
-
Page 11: Contact Details Supplier
Vehicle connection Mode 3 attache cable connector Type 2 3P+N (single-phase compatible) with pilots compliant (55161800 / 55161100 / 55161600 / 55321800 / with IEC 62191-1 and IEC 62196-2. 55321100 / 55321600 / 55320014 / 55320013 / Use of extension and adapter prohibited. 55160012 / 55321604) 55161800 / 55161100 / 55161600: 4m curl 3x16A 55160012: 4m straight 3x16A... -
Page 12: Eg Conformity Statement
13. EU DECLARATION OF CONFORMITY CE 2020 Directive 2014/35 / EU, Annex II p. 96/369, EMC 2014/30 / EU Ecotap® B.V. hereby declares. Established: Kruisbroeksestraat 23, 5281 RV Boxtel The charging station mentioned below complies with the requirements of the guidelines and standards mentioned below. Type: Ecotap®... - Page 13 Ecotap B.V. Kruisbroeksestraat 23 5281 RV Boxtel The Netherlands +31(0) 411 210 210 info@ecotap.nl www.ecotap.nl...
