8. TRANSPORTATION AND STORAGE

Transport the charging station (the core housing all of the technology) upright and prevent the coating from being damaged;
any such damage might result in corrosion. Provided that they are properly protected to prevent them being damaged, the
caps can be transported in a variety of positions. The charging station should be stored in a dry, damp-free area.

9. IN CASE OF MALFUNCTIONS

In case the DUO charging station is not functioning (properly), please contact the Ecotap® 24/7 helpdesk immediately
(phone number: 0031 (0) 411-745020) or a licensed mechanic in possession of measuring and testing equipment with auto
simulation.
WARNING!
All work performed on and modifications made to the charging station must comply with NEN1010 at the very least.
10. OPERATION AND CONTROL OF CHARGING COLUMN
The charging column can be operated with a charging card.
To charge with registration, you still need to register it.
Once registration is complete, the charging column can be used with any Electric Transport Charging Card (EV Charging Card)
or other suitable cards, mobile and key holders. When unused, the charging column will give an illuminated green signal with
some regularity.
Operation: Starting or stopping charging is done by holding the charging card in front of the scan point, you hear 1 sound
signal and the lamp starts flashing green.First, the plug is locked in the Mennekes charging socket.Then the charging column
communicates with the vehicle and the BackOffice system. Once all safety and payment requirements have been checked,
the maximum permissible charging current is transmitted. The charging procedure is now automatically switched on and the
lamp lights blue.When stopping the charging process, hold the pass in front of the scan point again. You will hear 2 beeps and
the lamp will flash green and go out as soon as the plug is unlocked. You can now safely remove the plug.

11. TECHNICAL SPECIFICATIONS

General characteristics
Reference number
Reference number (Eichrecht)
Dimension H x W x D (mm)
Casing material
Standard colour
Steel treatment
11. www.ecotap.nl
60111810 / 60321110 / 60161610 / 60321610 / 60081812
/ 60081112 / 60081612 / 60081813 / 60081114 / 60081
614/60102215/60102205/60080199 / 60080198
60451810 / 60451110 / 60451610
1400 x 220 x 240
Steel 2,2 mm
Body: Ral 6018 / Cover: Ral 9016 for 60451810 /
60081812 / 60081813 / 60102215 / 60102205 /
60080199 / 60080198
Body: Ral 7011 / Cover: Ral 9016 for 60111810 / 60321110 /
60451110 / 60081112 / 60081114
Body: Ral 9016 / Cover: Ral 9016 for 60161610 / 60321610
/ 60451610 / 60081612 / 60081614
Anti-corrosion (KTL) and powder coating
11-07-23
