SECURITY ADVICE
This Maintenance Guide for Ecotap AC charging stations describes the maintenance rules that must be
accurately respected to maximize the performance and lifespan of Ecotap charging stations, and to
guarantee the safety of your installation.
GENERAL
•
Charging stations must be installed in accordance with the installation rules described in the
instructions. In the event of an external shock, Ecotap charging stations must not be connected
or used.
•
Incorrect installation and/or use may lead to electric shock or fire hazards. Charging stations
must be used under normal conditions, i.e., they must not be subjected to values of Voltage /
Current / Frequency / Temperatures other than those specified in the instructions.
•
Any modification or repair of the charging station not authorized by Ecotap cancels the full
scope of the responsibilities, replacement rights and guarantees.
•
Use only the accessories recommended by Ecotap in the commercial catalogue and in the
manuals.
•
In order to constantly guarantee the highest levels of performance of our products, they may
be subject to change. Please check the accuracy of the product specifications during
maintenance operations and refer to the relevant instructions. For any questions or requests
for clarification, please contact your Ecotap assistance contact
•
The installation, use and maintenance of a charging station must be carried out by qualified,
trained, and authorized personnel, in accordance with the rules in force in each country.
Ecotap B.V. | Kruisbroeksestraat 23 | 5281 RV Boxtel The Netherlands | E: info@ecotap.nl
W: www.ecotap.nl | T: +31 (0) 411 – 210 210 | KvK: 54694949 | BTW: NL851405496 B01
Advertisement
Related Manuals for LEGRAND Ecotap Duo
Summary of Contents for LEGRAND Ecotap Duo
- Page 1 SECURITY ADVICE This Maintenance Guide for Ecotap AC charging stations describes the maintenance rules that must be accurately respected to maximize the performance and lifespan of Ecotap charging stations, and to guarantee the safety of your installation. GENERAL • Charging stations must be installed in accordance with the installation rules described in the instructions.
- Page 2 RISK OF ELECTRIC SHOCK, BURNS AND EXPLOSION • Wear PPE (Personal Protective Equipment) necessary for interventions on live products. • Respect the safety rules related to electrical work. • Improper electrical and mechanical use of equipment can be dangerous and risky and can result in bodily injury or property damage.
-
Page 3: Maintenance
MAINTENANCE GOAL OF THE MAINTENANCE During use, your charging station may be exposed to various factors such as low or high temperature variations, overvoltage’s, ambient pollution (e.g. dust, humidity, animal waste...), operating wear and tear (contactor...), etc. It is also important to regularly update the firmware of your charging station so that it can work properly with electric vehicles marketed after its initial commissioning. -
Page 4: Maintenance Planning
MAINTENANCE PLANNING OPERATIONS DESCRIPTION INTERVAL 1/5 - ASSEMBLY Clean the external mechanical part with water and soft solvent 6 months or product using a soft cloth. It’s not recommended to use high Clean the external every charging station pressure water to clean. intervention No Need to open the charging station. - Page 5 OPERATIONS DESCRIPTION INTERVAL 1/5 - ASSEMBLY Check the different ground connection between the Earth cable to Check the ground the different mechanical part. If needed adjust the earth connection. 1 year or every connection A continuity check must be done. intervention Need to open the charging station.
- Page 6 OPERATIONS DESCRIPTION INTERVAL 2/5 - MECHANICAL The appearance of the charging station should be checked. Check the sticker position and if they are still glued correctly. Check for damages and Check the integrity of the mechanical parts (panel, body, door 1 year or every blemishes on charging access…).
- Page 7 4/5 - MEASUREMENT Check the voltage value, make the measurement between: Phase to Phase; Phase to Neutral; Voltage measurement 1 year or every Phase to Earth; check intervention Neutral to Earth (close to 0V RMS); Need to open the charging station. OPERATIONS DESCRIPTION INTERVAL...
-
Page 8: Service Records
We strongly recommend that you keep an up-to-date maintenance booklet for each charging station with an indication of the verification and maintenance operations carried out. SERVICE RECORDS COMMISSIONING DATE MAINTENANCE CONTROL COMMENTS Date / After 6 months Visa Date / After 1 year Visa Date /...
