Pro-Form CARBON STRENGTH POWER TOWER User Manual page 8

2. Identify the Left Upright (2), and orient it as
shown.
Attach the Left Upright (2) to one of the
Bases (3) with two Support Plates (12), four
M10 x 70mm Bolts (19), and four M10 Locknuts
(16); do not tighten the Locknuts yet.
Attach the Right Upright (1) to the other Base
(3) in the same way.
3. Finish attaching the Left Upright (2) to the Base
(3) with two M10 x 95mm Bolts (18), two M10
Washers (17), and two M10 Locknuts (16); do
not tighten the Locknuts yet.
Finish attaching the Right Upright (1) to the
other Base (3) in the same way.
2
1
3
16
16
3
3
3
3
8
2
12
12
19
1
2
16 17
16
19
18
